Nursery Tray Making Machine
Supply Fully Automatic Four-station Servo Drive Plastic Seedling Tray Thermoforming Making Machine.
Free replacement parts
Send Inquiry
Product Introduction
| Technical Parameters | ||
| Station | Four stations | |
| Model | TTF-520AF | |
| Forming Area | 520mm x 400 mm | |
| Forming Depth (Max.) | 110mm | |
| Sheet thickness | 0.2-2.0mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.0 m³/min | |
| Water consumption | 0.7 m³/h | |
| Sheet width (Max.) | 570mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Used power | 55Kw | |
| Rated power | 110Kw | |
| Heating power | 75Kw | |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L11000*W4600*H2700mm | |
| Weight | About 11.0T | |
