Disposable Plastic Bread Container Thermoforming Machine

Model: TTF-520AF
Station：Four station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-2mm
Forming Speed (Max.):40times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.

Send Inquiry

Product Introduction

TTF series Disposable Plastic Bread Container Thermoforming Machine is forming, punching,cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency.
Disposable Plastic Bread Container Thermoforming Machine in one step with following process: transporting sheet, heating, forming, cutting, stacking and winding waste edge.
It is suitable for processing different materials, such as PP, PS, HIPS, PET, PVC, PLA etc. processing high transparency, high stretch, shallow stretch, round, square, upper and lower two-way stretch, flanged and other products, including trays, lids, fruit and vegetable boxes, flower pots, shells, seedling trays and plates, etc.

Disposable Plastic Bread Container Thermoforming Machine of Parameters

Model	TTF-520AF
Station	Four station
Mould Size (Max.)	520*400mm
Forming Depth (Max.)	110mm
Sheet thickness	0.2-2mm
Forming Speed (Max.)	40times/min
Air pressure	0.6-0.8mpa
Air consumption	3.0 m³/min
Water consumption	0.7m³/h
Sheet width (Max.)	550mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Power supply	AC 380V, 50Hz, Three-phase, Four-wire
Rated power	136Kw
Heating power	75Kw
Procedure	Forming-punching-cutting-stacking
Dimension	L10800W4200H2800mm
Weight	About 11.0T

APPLICATION of Disposable Plastic Bread Container Thermoforming Machine

Disposable plastic bread container thermoforming machine is used to making plastic salad box, vegetable container, plastic trays, egg trays, macaron container, lunch box and etc. It is completely driven by servo motor.

Structure & Design

Explore the detailed structure and configuration to see how our machine ensure precision, stability, and efficiency.

Heating Device

Temperature is controlled precisely (the difference is within ±1℃). The working life of the ceramic heater is long and adopts the fully enclosed oven. The temperature controlling system is better and saves more energy.

Operation Screen

Operator-friendly HMl, and the system has the function of remote connection. lntelligent operation, the whole machine is equipped with formula storage and automatic adjustment without shutdown.

Forming Station

Driven by servo motor to close the mold, with cylinder clamping frame and servo stretching function at the same time.

Punching Station

Servo motor driven, punching holes more accurate and complete Long-life, durable needle

Cutting Station

Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force

Stacking Station

Different stacking schemes can be formulated according to the customer's requirements.

Features of Disposable Plastic Bread Container Thermoforming Machine

The machine is positive and negative pressure forming combined.
It is low energy consumption, low noise, high degree of safety. Convenient operation and maintenance.
The machine are all driven by servo motor.
Sheet loading is automatic and the max weight can be 1000KG.
