Full-automatic Disposable Plastic Cup Forming Machine

Nom du produit : Plastic cup lid forming machine
Tension : 380V 3P 50HZ
Capacité de production :15-35 cycle/min
Plastic Type : PP, PS, PET, HIPS, PE
Usage :to produce plastic lids,medicine/food/daily/electronics/hardware

Send Inquiry

Product Introduction

The TQC-650B is a versatile Full-automatic Disposable Plastic Cup Forming Machine for PP, PS, HIPS, PET, PVC, PLA etc. Fully automatic PLC control for making cups, bowls, and lids. Speed: 35 cycles/min.

LITAI offers a range of fully automatic plastic cup forming machines designed for high-speed production of disposable cups using materials such as PP, PS, HIPS, PET, PVC, PLA etc. These machines utilize thermoforming technology, combining heating, forming, cutting, and stacking into a seamless process.

They are ideal for producing cold drink cups, ice cream cups, yogurt containers, deli cups, and even custom packaging lids, meeting the needs of both large-scale factories and OEM/ODM lines.

Full-automatic Disposable Plastic Cup Forming Machine of Technical Parameters

Model	TQC-650B
Max Forming Area	650*320mm
Max Forming Depth	125mm
Sheet Thickness	0.3-1.8mm
Suitable Sheet Width	660mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Air Pressure	0.6-0.8mpa
Air Consumption	2.0m³/min
Water Consumption	0.5m³/h
Rated Power	98Kw
Heating Power	78Kw
Power Supply	AC 380V,50Hz, Three-phase, Four-wire
Dimension	L7000W2000H3100mm
Weight	About 6T

Full-automatic Disposable Plastic Cup Forming Machine of Application

Full automatic disposable plastic cup forming machine is used for producing noodle box, bowls, lids, cups and etc. Material is used as PP/PS/PVC/PET/HIPS/corn starch.
