Pet Plastic Cup Thermoforming Machine
Model: TQC-650B
High Efficiency: Reduces cycle time by 30% with servo-motor drive.
Precision: ±0.01mm repeatability for complex forming.
Certified: CE & ISO 9001 Compliant standards.
Customizable: Worktable size and stroke tailored to needs.
Plastic cups, bowls and milk tea cups using PP, PET, PLA and HIPS materials.
TQC-650B PET plastic cup thermoforming machine adopts servo motor for sheet feeding and stretching, PLC for programme, touch screen for operation. Runing stable, having low noise, with high efficiency, suitable for producing disposable products like plastic PET cups, ice cream cups, cold drinking cups, yogurt cups, trays, plates, bowls, covers, lids, containers, etc.
Design Features of Pet Plastic Cup Thermoforming Machine:
1.In mold cutting with high accuracy and high yield products.
2.Journey is Adjustable, easy to change mold, suitable for different specifications.
3.Easy in installation and maintation.
4. Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
5.Running in a high automatization and intellectualization.
6.This model has four pillars design, that means it can get bigger forming area and its capacity is also bigger.
Parameter of Pet Plastic Cup Thermoforming Machine:
| Model | TQC-650B |
| Max Forming Area | 650*320mm |
| Max Forming Depth | 125mm |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 2.0m³/min |
| Water Consumption | 0.5m³/h |
| Rated Power | 98Kw |
| Heating Power | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L7000*W2000*H3100mm |
| Weight | About 6T |
FAQ:
Q1 : Why Choose Litai Machinery?
A: Litai Machinery got 17 years manufacturing experience. The most advantage is we got the most professional experts for after sale service, we will be patient and passionately to solve your problems.
Q2 : Are you a factory or trading company?
A: We are a factory.
Q3 : Delivery time?
A: Usually two months after confirmation.
Q4 : What are the payment term?
A:30% as deposit by T/T, and the balance before shipment.
Q5 : What is the MOQ for PET plastic cup thermoforming machine?
A: 1 Set, more is ok.
Q6 : Where is the loading port?
A: Ningbo Port.
Q7 : Packing of the machine?
A: Most of machines will pack with plywood case or fumigation wooden case(according to customers' requirement).
