PS Lid Capping Machine

Model: TQC-650B
Mould Size (Max.): 650mm x 300 mm
Forming Depth (Max.): 125mm/180mm
Sheet width (Max.): 660mm
Main Motor Power: 98Kw
Heating power: 78KW
Dimension: L7000 x W2000 x H3100mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials

Send Inquiry

Product Introduction

PS Lid Capping Machine adopts Hydraulic driven system. but which sheet conveyor parts and streching parts use two servo motors for ensuring high accurate sheet converying and stable streching effects .
This macine use PLC touch screen as operation system more easy to operating, and the machine structure use four pillar type making machine more stable and having low noise, . there are 120 pieces ceremic tiles in the heating area to ensure high temperature needs in TQC-650B Little maintenance effort required and long intervals between maintenances Most of Components are from multi-national suppliers assures a reliability and worldwide compatibility.
The forming area is 650 x 320mm, forming depth 180mm, max production speed 35 cycle/min.

PS Lid Capping Machine of Parameters

Model	TQC-650B
Mould Size (Max.)	650*300mm
Sheet width	660mm(Max)
Max. Forming Depth	125-180mm(custom height)
Max. Forming Speed	30times/min
Sheet Thickness	0.3-1.8mm
Suitable Sheet Width	660mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Air Pressure	0.6-0.8mpa
Air Consumption	2.0m³/min
Water Consumption	0.5m³/h
Rated Power	98Kw
Heating Power	78Kw
Power Supply	AC 380V,50Hz, Three-phase, Four-wire
Dimension	L7000W2000H3100mm
Weight	About 6T
