Plastic Pp Cup Machine

Plastic Pp Cup Machine

TQC Plastic thermoforming machine adopts Japan Yaskawa servo motor for sheet feeding and stretching, Germany Siemens PLC for programme, touch screen for operation, stable, low noise, high efficiency, suitable for producing disposable products like plastic bowls, ice cream cups, cold drinking cups, yogurt cups, trays, plates, covers, lids, containers, etc.
Send Inquiry
Product Introduction

Plastic Pp Cup Machine

2


Plastic Pp Cup Machine------- Technical parameters


Technical Parameters
Model
TQC-750
TQC-650B
Max. Forming Area
750*480mm
650*320mm
Max. Forming Depth
125-180mm(custom height)
Sheet Thickness
0.3-1.8mm
Sheet Width
760mm
650mm
Max. Forming Speed
30 times/min
Air Pressure
0.6-0.8mpa
Air Consumption
3.0m³/min
2.0m³/min
Water Consumption
0.7m³/h
0.5m³/h
Rated Power
140Kw
98Kw
Used Power
98Kw
72Kw
Power Supply
AC 380V,50Hz, Three-phase, Four-wire
Dimension
L8500*W2200*H3200mm
L7000*W2000*H3100mm
Weight
About 6.5T
About 5T

Plastic Pp Cup Machine-------Samples:


photobank (10)







  Packing

paste-pic-dp_uuid_ungf5


Our Quality

We have got CE and ISO9001certification.With the mind to offer customers the best plastic thermoforming machine,we have got a good reputation over the world.We will supply you the best quality plastic packing machine of good price continuously as we did in the past 18 years.


FAQ:

1. The capacity of production (per hour or per month)?
It depends on your samples.Forming Area is 650mm*320mm

2. Is the product include the engineer services (to explain us how does it works in our factory)?
Yes,we can engineers to customers factory for machine installation and training.

3.Guarantee time and after-sale

One year guarantee time, after one year , we have professional after-sales department providing best service if customer has any problems.

4.What this machine can do?

It is widly used for thermoforming packaging container, such as PP/PET cups, boxes, bowls, all thin wall thickness containers. Also milk cups, jelly cups, snow cake cups, disposable drinking water cup, instant noodles bowl, snack box, food box etc.

5.What is the delivery time?

It takes about 45-60 days usually after receipt of your deposit. Pls check with us if available stock.
