PP Plastic Cup Making Machine
Model:TFC-730
Mould Size (Max.): 730×320mm
Forming Depth (Max.): 180mm
Sheet width (Max.): 510-760mm
No-load Speed: 48 Cycles/Min
Main Motor Power: 11.8KW
Heating power: 150.2KW
Dimension: L11000*W2900*H3500mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
Pp Plastic Cup Making Machine TFC-730 is the latest product developed by our company, mainly used to produce plastic cup products of different specifications. The machine adopts positive and negative pressure molding, equipped with a mold turning system under full servo motor control, and uses two pairs of conjugate cam transmission connecting rods to complete the tilting, lifting and punching of the mold table. It is a new type of equipment developed for high output, low energy consumption, high stability, high automation and other requirements, providing a perfect solution for medium and high capacity disposable plastic cups.
PP Plastic Cup Making Machine------Technical Parameters
| Model | TFC-730 |
| Mould Size (Max.) | 730*320mm |
| Sheet width | 510~760mm |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 16-42times/min |
| Sheet Thickness | 0.3-2.0mm |
| Suitable Sheet Width | 510-760mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 4-5m³/min |
| Water Consumption | 15.6m³/h |
| Rated Power | 188.5Kw |
| Heating Power | 151.7Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L10700*W3000*H3215mm |
| Weight | About 15T |
Features of PP Plastic Cup Making Machine
1. Suitable for Multiple Plastic Materials
The machine supports PP, PET, PLA, PVC, HIPS, BOPS, and other thermoforming materials, making it suitable for disposable food packaging and eco-friendly biodegradable cup production.
2. Full Servo Hydraulic Control System
The machine adopts a full servo hydraulic control system to ensure smooth operation, stronger forming power, and more stable product quality during high-speed production.
3. Large Forming Area and High Production Speed
With a maximum forming area of 750 × 480mm and production speed up to 35 strokes per minute, the machine is suitable for medium and large-scale disposable cup manufacturing.
4. PLC Intelligent Touch Screen Control
The touch screen control system supports electrical adjustment, recipe storage, temperature control, and remote maintenance, helping operators reduce workload and improve production efficiency.
Sample Pictures
The equipment supports the processing of a variety of materials, including PP, PS, PET, PVC, PLA, etc., and can produce cups of different materials. At the same time, the mold table can be flexibly adjusted to suit the production of various cup types.
