Automatic Plastic Clamshell Forming Machine

Model: TTF-820A
Max.Forming Area: 820*650mm
Max.Forming Height: 140mm
Max.Sheet Thickness(mm): 1.2 mm
Forming Speed (Max.): 40times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.

Send Inquiry

Product Introduction

As a professional Automatic Plastic Clamshell Forming Machine manufacturer, LITAI Machine provides high-performance solutions for the efficient production of rigid plastic food packaging, converting plastic sheets into precise, hygienic, and durable containers such as disposable cups, yogurt containers, fruit punnets, and biscuit trays, with machines compatible with PP, PS, PET, and PVC materials and engineered with fully servo-driven systems to ensure stable high-speed operation, accurate forming and cutting, reduced material waste, and consistent production quality.

Automatic Plastic Clamshell Forming Machine Working Principle:

Plastic thermoforming (blister) technology is a plastic processing technology that processes thermoplastic sheets (plates) into various products. First, the plastic sheet (plate) is heated to a softened state in a heating furnace, and then placed in a forming mold, and under the action of external force (vacuum, positive pressure, or mechanical), it is tightly attached to the surface of the mold to form a and detailed contours of the fit surface. After cooling, shaping, trimming, and other processes, the desired product is obtained.

Automatic Plastic Clamshell Forming Machine of Parameter:

Model	TTF-820A
Station	Three station
Mould Size (Max.)	820*650mm
Forming Depth (Max.)	140mm
Sheet thickness	0.2-2mm
Forming Speed (Max.)	40times/min
Air pressure	0.6-0.8mpa
Air consumption	4.0m³/min
Water consumption	0.7m³/h
Sheet width (Max.)	850mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Power supply	AC 380V, 50Hz, Three-phase, Four-wire
Rated power	202Kw
Heating power	140Kw
Procedure	Forming-cutting-stacking
Dimension	L12800W4650H2900mm
Weight	About 17T

Application of Automatic Plastic Clamshell Forming Machine:

Automatic Plastic Clamshell forming machine is sheet loading-sheet heating-forming-cutting-stacking-waste material rewinding-finished products.

product-1200-500

Specification:

1.Suitable products: PP/PS/PET/HIPS/PVC/Corn Starch and etc.

2. Application goods: Egg trays, lids, clam shell packing, bowls, chocolate box, cake box, sandwich box and etc.

3. The machine is totally running by servo motor.

4. Easy to change the mould by producing different goods.

Machine detail

Heating Device

Energy Efficiency save 30%
Elstein ceramic heaters, individually adjustable(line by line)
Can control the temperature by PLC directly

Operation Screen

Live Data Display – Real-time temperature, pressure, and cycle status.
Emergency Stop & Alarms – Quick response to hazards.
Multi-Language Support – For global operators.

Forming Station

Max mould size:820*650mm
Max depth:140mm
Servo driven plug assist on top forming station
Stable square struction,provide stable forming

Cutting Station

Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force

Stacking Station

Different stacking schemes can be formulated according to the customer's requirements.

Waste recycling

Edge trim is fed to the waste rewinding system for recycling. Its special clutch automatically cuts power when the roll becomes too large, preventing overload and extending motor lifespan.
