Polypropylene Sheet Roller Extruder Machine
Model: TJ-750E
Sheet width (Max.): 750mm
The Range of Sheet Thickness: 0.3~1.8mm
Rated Power: 320KW
Screw Rod Diameter: 125mm
Suitable Materials: PP/PS
Polypropylene Sheet Roller Extruder Machine
Sample
APPLICATION AREA
The TJ-750E is a high-efficiency Plastic Sheet Extrusion Line for PP, HIPS, and PE. Max output 350kg/h with energy recovery system. Ideal for thermoforming sheets and stationery.
The Plastic Sheet Extrusion Line is a robust manufacturing solution designed for producing high-quality plastic rolls. It is specifically engineered to process Polypropylene (PP), High Impact Polystyrene (HIPS), and Polyethylene (PE) resins. With a high output capacity of 350kg/h, this machine produces sheets with uniform thickness and excellent surface finish, making it the primary equipment for supplying material to thermoforming machines and stationery manufacturers.
Parameters of Polypropylene Sheet Roller Extruder Machine
| Model | TJ-750E |
| Maximum output | 400kg/h@0.7mm |
| Suitable Sheet | PP,PS |
| Sheet Width (Max.) | 750mm |
| Mould width | 950mm |
| Sheet Thickness | 0.3-2.0mm |
| Compressed air source pressure | 0.6-0.8Mpa |
| Screw Rod Dia | 125mm |
| Screw L/D Ratio | 35:1 |
| Max. Output | 400kg/hour |
| Rated Current | 500A |
| Rated Powe | 320kW |
| Energy consumption | 220kW |
| Main Motor Power | 160kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L15388*W3615*H2900mm |
| Weight | About 12T |
