Pp Plastic Sheet Making Machine
PP Plastic Sheet Making Machine - High-Efficiency Polypropylene Sheet Production Line
Product Overview
The PP Plastic Sheet Making Machine is an energy-efficient extrusion system designed for manufacturing premium-quality polypropylene (PP) sheets with excellent chemical resistance, thermal stability, and mechanical strength. Ideal for Food packaging, plastic packaging, electronic packaging, agriculture, medicine industries, this advanced equipment combines intelligent automation with eco-friendly production to deliver consistent, high-output performance.
| Technical Parameters | ||
| Model | TJ-750C | TJ-750D |
| Suitable Sheet | PP,PS | |
| Sheet Width (Max.) | 750mm | 770mm |
| Sheet Thickness | 0.3-2.0mm | |
| Screw Rod Dia | 125mm | 110mm |
| Screw L/D Ratio | 35:1 | 32:1 |
| Max. Output | 400kg/hour | 240kg/hour |
| Main Motor Power | 132kw | 75kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire | |
| Dimension | L15388*W3615*H2900mm | L14000*W2600*H1800mm |
| Weight | About 12T | About 8T |
Key Features & Benefits
LITAI MACHINERY CO., LTD.
High-Speed Extrusion Technology
- Equipped with precision screws and barrels for uniform plasticization and efficient material flow.
- Production capacity optimized for continuous, large-scale PP sheet manufacturing.
Smart PLC Control System
- Fully automated operation via PLC + HMI interface for real-time parameter adjustments.
- Ensures consistent thickness (0.2-2mm customizable) and minimal material waste.
Multi-Functional Design
- Quick mold changes support diverse sheet dimensions (widths: 300-770mm).
- Optional online lamination/cutting units to expand product applications.
Energy-Saving & Sustainable
- 30% reduced power consumption with servo-driven motors and optimized heating zones.
- 100% scrap recycling system complies with green manufacturing standards.
Premium Output Quality
- Advanced chill-roll cooling + stretching system guarantees bubble-free, smooth surfaces.
- Meets ISO/CE standards for tensile strength and dimensional stability.
Global After-Sales Support
- 24/7 technical assistance, on-site installation, and operator training included.
- Lifetime maintenance plans to maximize equipment uptime (98%+).
Why Choose Our PP Sheet Machine?
- 20+ years of extrusion technology expertise.
- CE-certified with 1-year warranty coverage.
- Customizable configurations for PP, PP+Corn starch blends, or recycled materials.
-
20years +Production experience
-
1 year+Warranty period
