Pp Plastic Sheet Machinery

Sample Of Pp Plastic Sheet Machinery

Pp Plastic Sheet Machinery has a hydraulic filter net changer:

1. One Worm-Gear Case

2. Filter Size：300mm*40mm

3.Net Dia：3-3.5mm

4.Heating power：7.2kw

5.Hydraulic system drive to change net, include two nets.

6.Hydraulic pump:Drive to change net, using nitriding treatment of good hardness, high temperature resistance, corrosion resistance.

Pp Plastic Sheet Machinery Technical Parameters

Key Features & Energy Saving Design

Advanced Extruder Design: The extruder barrel features an optimized low-height design for easier operation. Crucially, it is installed with high-grade insulation components to minimize heat loss, ensuring stable processing temperatures.

Energy Recovery System: The machine is engineered to recover energy generated from the high-speed screw rotation friction. This heat is recirculated to assist in the drying or heating process, significantly reducing overall electricity consumption compared to standard models.

Precision Calendering: Equipped with a robust 3-roller calender system (400mm diameter). The roller distance can be precisely adjusted (0-50mm) to control sheet thickness from 0.15mm to 2mm with tight tolerances.

High Output Screw: Uses a specialized 100mm Single Screw with a 33:1 L/D ratio. This long screw design ensures thorough plasticization and mixing of the material, resulting in a consistent melt flow for high-speed extrusion.

Complete Line Integration: The line includes the Extruder, Hydraulic Screen Changer for non-stop filtering, T-Die, 3-Roll Calender, Cooling Bracket, Haul-off Unit, and Double Station Rewinder for continuous roll changing.
