Packing Yogurt Cup Machine
High Efficiency: Reduces cycle time by 30% with servo-motor drive.
Precision: ±0.01mm repeatability for complex forming.
Certified: CE & ISO 9001 Compliant standards.
Customizable: Worktable size and stroke tailored to needs.
Send Inquiry
Product Introduction
Packing Yogurt Cup Machine----Description
PP,PS,HIPS,PVC,AND PET plastic sheets,which can be widely used to produce all kinds of plastic boxes,containers and other plastic wares,such as ice-cream cups,milk cups,chocolate package boxes,candy boxes and fast-food boxes etc.
This machine is mainly used for producing disposable plastic vessels,such as tea cup,milk cup,jelly cup,instant noodles bowl and other plastic product,etc.It can produce such as PP,PE,PS and ABS,etc
Packing Yogurt Cup Machine of Parameter:
| Model | TQC-750 | TQC-650B |
| Mould Size (Max.) | 750*480mm | 650*300mm |
| Max. Forming Depth | 125-180mm(custom height) | 125mm |
| Max. Forming Speed | 30times/min | |
| Sheet Thickness | 0.3-1.8mm | |
| Suitable Sheet Width | 770mm | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Air Pressure | 0.6-0.8mpa | |
| Air Consumption | 3.0m³/min | 2.0m³/min |
| Water Consumption | 0.7m³/h | 0.5m³/h |
| Rated Power | 173Kw | 98Kw |
| Heating Power | 146Kw | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire | |
| Dimension | L8500*W2300*H3300mm | L7000*W2000*H3100mm |
| Weight | About 8T | About 6T |
