Full-automatic Cup Making Machine
The TQC-750S is engineered for mass production of:
Beverage Cups: Water cups, Coffee cups, Bubble tea cups (PP/PET).
Dairy Packaging: Yogurt cups, Ice cream cups, Jelly cups.
Eco-Friendly Packaging: PLA biodegradable cups and bowls.
Invest in High Speed: Ready to upgrade your output to 42 cycles/minute?
Send Inquiry
Product Introduction
TQC-750s fully automatic servo plastic cup making machine is designed to produce cup shape products. Such as disposable plastic cup, bowls, plates, lids, etc. This plastic cup thermoforming making machine have high productin efficiency with its forming and cutting two-in-one station. Controlled by microcomputer, this cup thermoforming machine can completes the plastic cup production at one time by conveying, heating, forming and cutting, and sheet waste winding.
Scope of application:
It is suitable for the molding of plastic sheets such as HIPS, PS, PP, PVC, PET, etc., and produces various packaging products such as boxes, plates, trays, bowls and lids. Such as: milk cup, jelly cup, disposable drink cup, instant noodle bowl.
Technical Parameters of Full-automatic Cup Making Machine
| Model | TQC-750S |
| Mould Size (Max.) | 750*480mm |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 770mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 3.0m³/min |
| Water Consumption | 0.7m³/h |
| Rated Power | 207Kw |
| Heating Power | 180Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L7900*W2300*H3400mm |
| Weight | About 8.2T |
Production Procedure:
Functional Characteristics Of Full-automatic Cup Making Machine?
- Fully servo-driven, silent, vibration-free, excellent thermoforming, and high speed.
- Compact design, occupying minimal floor space.
- Integrates sheet feeding, heating, stretching, forming, and trimming in one process.
- Automatic unloading device allows adjustable production parameters without material waste.
- One-to-one intelligent temperature control system in the electric furnace for even heating, energy efficiency, rapid temperature rise, and three low-temperature baking cycles.
- Servo-driven forming and cutting molds with bi-directionally adjustable stroke; the upper mold's closing direction is electrically adjustable for easy height adjustments and faster, vibration-free operation.
- PLC for automatic cutting, counting, and transportation.
- Only 1-2 operators needed for packing.
Finished Products:
