PP Disposable Cup Making Machine
Model: TQC-750
1,The dynamic structure adopts the optimized design of the conjugate cam, and the operation is more stable.
2,Quick mold change design greatly improves production efficiency.
3,The mold table is designed with a lifting function, which can directly adjust the depth of the mold entering the knife.
4,Digital screen setting and intelligent data storage system.
5,The speed is up to 40 cycles/min.
Send Inquiry
Product Introduction
TQC-750 automatic thermoforming machine is suitable for producing the PP, PS, PE, PET and PVC cup, container, tray and lid.It is easily operable, labor-saving, less maintenance and high efficient. CMM thermoforming machine adopts the hydraulic system with pneumatic system, compared with the traditional mechanical cam system, its advantages are less working noise, stronger punching force, more stable forming quality and longer service life
Pp Disposable Cup Making Machine----Finished Product Samples:
Pp Disposable Cup Making Machine----Technical Parameters
| Model | TQC-750 |
| Mould Size (Max.) | 750*480mm |
| Max. Forming Depth | 125-180mm(custom height) |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 770mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 3.0m³/min |
| Water Consumption | 0.7m³/h |
| Rated Power | 173Kw |
| Heating Power | 146Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L8500*W2300*H3300mm |
| Weight | About 8T |
Functional Characteristics Of PP Disposable Cup Making Machine?
- Fully servo-driven, silent, vibration-free, excellent thermoforming, and high speed.
- Compact design, occupying minimal floor space.
- Integrates sheet feeding, heating, stretching, forming, and trimming in one process.
- Automatic unloading device allows adjustable production parameters without material waste.
- One-to-one intelligent temperature control system in the electric furnace for even heating, energy efficiency, rapid temperature rise, and three low-temperature baking cycles.
- Servo-driven forming and cutting molds with bi-directionally adjustable stroke; the upper mold's closing direction is electrically adjustable for easy height adjustments and faster, vibration-free operation.
- PLC for automatic cutting, counting, and transportation.
- Only 1-2 operators needed for packing.
