Disposable PET Plastic Egg Tray Thermoforming Machine

TTF-700AF plastic thermoforming machine can produce thermoformed PET egg trays, takeaway boxes, packaging boxes, fruit boxes, biscuit boxes, change different molds to make a machine can produce a variety of disposable plastic products, TTF-700AF is a complete Automatic four-station equipment, which integrates automatic feeding, heating, forming, punching, cutting, stacking, and waste recycling. The production speed can reach 30 times per minute, and the standard consumption of plastic sheet rolls per hour is 180-250 kg , The equipment has punching holes, some plastic boxes, seedling trays, fruit boxes can be punched, whether it is a round hole, a square, or a special shape, there is no problem. This is also the difference between the three-station.

Send Inquiry

Download

Product Introduction

Samples：it can produce plastic trays, containers, boxes, lids, etc.

Recommended Products：

Product Paramenters:

Technical Parameters
Station	Four stations	Three station	Four stations	Three station
Model	TTF-700AF	TTF-700A	TTF-520AF	TTF-520A
Forming Area	700mm x 600 mm		520mm x 400 mm
Forming Depth (Max.)	135mm		110mm
Sheet thickness	0.2-2.0mm
Forming Speed (Max.)	30times/min
Air pressure	0.6-0.8mpa
Air consumption	3.6 m³/min		3.0 m³/min
Water consumption	0.7 m³/h
Sheet width (Max.)	730mm		570mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Power supply	AC 380V, 50Hz, Three-phase, Four-wire
Used power	105Kw	95Kw	55Kw	50Kw
Rated power	210Kw	190kw	110Kw	100Kw
Heating power	118Kw		75Kw
Procedure	Forming-punching-cutting-stacking	Forming-cutting-stacking	Forming-punching-cutting-stacking	Forming-cutting-stacking
Dimension	L13000W4700H2750mm	L11500W4700H2750mm	L11000W4600H2700mm	L9700W4600H2700mm
Weight	About 25.0T	About 19.0T	About 11.0T	About 9.0T

Main Electrical Components
MODEL/PARTS	TTF520A/AF	TTF700A/AF
Filter	CKD(Japan)
Forming Valve	NORGER(UK)
Touch Screen	DELTA	KUNLUN TONGTAI
Proximity Switch	ROCKWELL(USA)
Temperature Control Module	WEST(UK)
AC Contactor/Circuit Breaker/Button	SCHNEIDER(France)
Intermediate Relay	IDEC(Japan)
Intermediate Relay Base	OMRON(Japan)
PLC/Servo Motor	DELTA(Taiwan)
Safety Door	-	Panasonic(Japan)
Sheet Sagging Detection	-	Sick(Germany)

Features：

Main Function：

1.positive and negative pressure forming device.

2.vacuum forming device.
3.touch screen computer temperature module point to point control function.
4.air control device.
5.cooling device.
6.die, mold temperature control function.
7.automatic punching and cutting function.
8.automatic stack counting function.
9.edge automatic rewinding function.

10.safety protection device.

1.Every station is driven by the eccentric crank linkage structure.

2.Feeding and heating part have optoelectronic switch in order to prevent error operating from production process.

3.The toothed chain made of 65#Mn, helping convey sheet. Aluminum rails with water cooling, save water.

4.The machine adopts PID temperature system, it shows high precision, and temperature control tolerance ＜1℃.

5.There is a rapid mould change device, which shortens the time for mould change extremely.

6.There is a rapid mould change device, which shortens the time for mould change extremely.

7.Low barycenter and height of finished products as well as steady running ensures easy operation and friendly viewing.

8.There is an alarm function of the sliding doors.

Contact Us：

Facebook

https://pse.is/3urql5

https://pse.is/3ythvl

YouTube

https://pse.is/3zkhvj

Instagram

https://pse.is/3yhe6m

https://pse.is/3vd57m

Tiwtter

https://pse.is/3z675l

Official website

http://www.litai.cc/

Tik Tok

http://pesc.pw/478rpe

Made in China

https://pse.is/3rh2nv

Company Profile：

Exhibition & Customers：

FAQ：

Q1: Are you a factory or trading company?

A1: We are a factory, and we export our machines to more than 80 countries since 2001.

Q2: How long is the warranty period?

A2: We have a professional QC department in charge of products' quality.

Q3: How long is the warranty period?

A3: 13months calculated from the date of shipment from our factory.During warranty period, except the artificial factor, the spares are free to maintenance, beyond the warranty time, the buyer needs to pay the spare charge and shipping cost.

Q4: How to install the machine?

A4: We will send technician to your factory to install the machine, and teach your workers to use it. You pay all related costs, including visa charge, double-way tickets, hotel, meals, and technician salary.
