Disposable Cup Production Line

TFC-730 Disposable Cup Production Line is our lasted developed product, It's mainly for manufacturing different plastic cups products.
With forming area 730*320mm, and max depth 170mm, the machine can meet all different kind of cups production request. The max running speed 42 cycles/min, it helps to develop for high output, low energy consumption, high stability, high automation and other requirements, providing the perfect solution for medium and high capacity disposable cups.

Application of Disposable Cup Production Line:

1. Disposable cup production line machine can be used in the production of plastic cup, cold drinking cup, boxes and bowls, trays and lids and etc.
2. The machine is controlled by PLC and touch screen.
3. Automatic lubricating system to avoid machine damage.

Parameters of Disposable Cup Production Line

Equipment Details:

1. PLC Control: Siemens PLC for accurate performance and recipe storage.
2.  Mold Guide Columns: Stable four-column design (40R steel, hard chrome plated) for durability and high accuracy in mold operation.
3. Temperature Control: PID regulation with Taiwan Yangming modules; temperature deviation within ±1 degree across 20 channels.
4. Sheet Feeding Chain: Double-row roller chain with teeth, supported by quenched 40Cr guide rails for enhanced durability.
5. Hydraulic System: Joint-venture oil pump with imported electromagnetic valves from Taiwan.
6. Heater: Tianbao curved electric heating tiles for high efficiency and safety.
7. Servo Stretching: Huichuan servo motors control mold speed for uniform strength and consistent bottom thickness, optimizing material usage.
8. Accessories: Air circuit control with AIRTAC cylinders, utilizing reliable Japanese and Taiwanese components for longevity.

Our flip-top plastic cup machine can be integrated with packaging production lines, significantly enhancing productivity while reducing labor costs. This fully automated system enables seamless production-to-packaging integration, requiring only ‌2 operators‌ to complete the entire process-cutting manpower needs and boosting efficiency. ‌40%+ faster output‌ vs. manual lines, ‌60% labor cost reduction‌.
