Four Station Plastic Lid Thermoforming Machine
Model: TTF-520AF
Station：Four station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-2mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Four Station Plastic Lid Thermoforming Machine is used to produce high efficiency plastic lids, fruit box, egg tray, seeding trays, soap tray, bisuit box and etc. The machine is totally driven by servo motor and PLC and touch screen used by Delta from Germany.
Thermoforming Machine Working Principle:
Plastic thermoforming (blister) technology is a plastic processing technology that processes thermoplastic sheets (plates) into various products. First, the plastic sheet (plate) is heated to a softened state in a heating furnace, and then placed in a forming mold, and under the action of external force (vacuum, positive pressure, or mechanical), it is tightly attached to the surface of the mold to form a and detailed contours of the fit surface. After cooling, shaping, trimming, and other processes, the desired product is obtained.
Four Station Plastic Lid Thermoforming Machine of Parameter
| Model | TTF-520AF |
| Station | Four station |
| Mould Size (Max.) | 520*400mm |
| Forming Depth (Max.) | 110mm |
| Sheet thickness | 0.2-2mm |
| Forming Speed (Max.) | 40times/min |
| Air pressure | 0.6-0.8mpa |
| Air consumption | 3.0 m³/min |
| Water consumption | 0.7m³/h |
| Sheet width (Max.) | 550mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire |
| Rated power | 136Kw |
| Heating power | 75Kw |
| Procedure | Forming-punching-cutting-stacking |
| Dimension | L10800*W4200*H2800mm |
| Weight | About 11.0T |
SAMPLES
Four Station Plastic Lid Thermoforming Machine of Features
1. Four station plastic lid thermoforming machine can achieve multi-purpose in one machine
2. The machine can be operated smoothly with low noise and strong mould clamping force.
3. Suitable material is PP/PS/PET/PVC/HIPS/Corn Starch and etc.
4. Max forming depth: 100mm
5. Max forming area: 520x400mm
Structure & Design
Heating Device
Energy Efficiency save 30%
Elstein ceramic heaters, individually adjustable(line by line)
Can control the temperature by PLC directly
Operation Screen
Live Data Display – Shows temperature, pressure, and cycle status in real time.
mergency Stop & Alarms – Ensures quick response to operational hazards.
Multi-Language Support – Accommodates global operators.
Forming Station
Max mould size:520*400mm
Max depth:110mm
Servo driven plug assist on top forming station
Stable square struction,provide stable forming
Punching Station
Servo motor driven, punching holes more accurate and complete Long-life, durable needle
Cutting Station
Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force
Stacking Station
Different stacking schemes can be formulated according to the customer's requirements.
