Automatic Glass Cup Thermoforming Machine

Product Description

Automatic glass cup forming machine adopts Hydraulic driven system. but which sheet conveyor parts and streching parts use two servo motors for ensuring high accurate sheet converying and stable streching effects .

This macine use PLC touch screen as operation system more easy to operating, and the machine structure use four pillar type making machine more stable and having low noise, .

there are 120 pieces ceremic tiles in the heating area to ensure high temperature needs in TQC-650B

Little maintenance effort required and long intervals between maintenances

Most of Components are from multi-national suppliers assures a reliability and worldwide compatibility

Technical Parameter of Automatic Glass Cup Forming Machine:

Machine model:TQC-650B

Max.Forming Area (mm) :  650 x 320

Max.Forming Depth(mm):125 (over 125mm machine can be customized need to be charged)

Suitable sheet thickness (mm): 0.3~1.8

Max.Sheet Width (mm) : 660mm

Forming Speed (circle times/min) : 30

Air pressure (Mpa)  :0.6~0.8

Air Consumption (m³/min) ：2

Water Consumption(m³/H)  : 0.5

Rated Power (KWH)  : 98

Power Supply : 380V 50Hz 3p 4 wires (can be customized to be charged)

Dimensions:(L*W*H mm) : 7000 * 2000 * 3100

Machine Weight （Ton） : 5

Product Samples displayed:

Features:

1.  The stretching plugs inside the upper mould are controlled by servo motor.

2.  The sheet is transfered by pin chain. (The pin chain is driven by servo motor. The feeding length can be adjusted according to your need)

3.  It adopts four pillars structure to fix the mold.

4.  The production process include sheet feeding, sheet heating, plugs stretching, forming and in-mould cutting and blow the final products out.

Machine Details Picture:

The above picture from left to right is touch screen, guide plate. servo motor,  mold.
