Corn Starch Cup Forming Machine

Plastic Cup Thermoforming & Cooling machine & Stacking & Counting & Packing Machine, This machine only needs one or two three workers to control, realize the full-automatic, it is modern life style machine, save worker salary, use machine to work instead of mankind to work.

Send Inquiry

Product Introduction

The thermoforming Machine adopt Servo motor feeding and PLC control system.Can produce various kind of disposable plastic cup, plastic containers of cooling drinks, sour milk, ice-cream,fast food, or instant noodle, as well as different kinds of merchandise packages of medicine, toy,journal. textile and light industry, etc.

Corn Starch Cup Forming Machine of Advantage:

1.It adopts new drve,which features in stable operation,low noise and con venient operation and mainetenance.
2.Four-guide-pillar structure features in stable formation,small vibration and high percision.
3.Its caterplillar track adopts free-withdrawal design,which is convenient and quick for replacing mold.
4.Servo motor feeds sheet which a high precision.
5.Apply servo motor to extrude into formation,which features in quick extruding speed,quick reaction,accurate location and convenient opertion.

TQC details.jpg

Corn Starch Cup Forming Machine of Parameter:

Model	TQC-750S	TQC-750	TQC-650B
Mould Size (Max.)	750*480mm	750*480mm	650*300mm
Max. Forming Depth	180mm	125-180mm(custom height)	125mm
Max. Forming Speed	30times/min
Sheet Thickness	0.3-1.8mm
Suitable Sheet Width	770mm		660mm
Suitable Sheet	PP, PS, HIPS, PET, PVC, PLA etc.
Air Pressure	0.6-0.8mpa
Air Consumption	3.0m³/min		2.0m³/min
Water Consumption	0.7m³/h		0.5m³/h
Rated Power	207Kw	173Kw	98Kw
Heating Power	180Kw	146Kw	78Kw
Power Supply	AC 380V,50Hz, Three-phase, Four-wire
Dimension	L7900W2300H3400mm	L8500W2300H3300mm	L7000W2000H3100mm
Weight	About 8.2T	About 8T	About 6T
