Kids Plastic Lunch Boxes Thermoforming Machine

This plastic lunch boxes thermoforming machine developed by combining the domestic and foreign equipment and advantages, is a set of hydraulic pneumatic servo drive for an automatic forming cutting stacking machine.
The main electrical components, such as vacuum pump,PLC,made in Japan and Germany, ensure the reliability of the equipment operation, and can be used for hot forming process many kinds of plastic material, it can produce PS,PVC,PE,PP,PET,HIPS etc all kinds of packaging products, materials used in food, medical supplies, electrical components, tourism products, toys, textile, etc.

Machine Parameter of Plastic Lunch Boxes Thermoforming Machine:

Application of Kids Plastic Lunch Boxes Thermoforming Machine

It is used to form plastic sheets such as PP PS HIPS PVC PET, etc. It can be widely used in the production of various plastic boxes, containers and other plastic products, such as ice cream cups, milk cups, chocolates, packaging boxes, candy boxes, fast food boxes, food boxes, etc.

Advantages of Plastic Lunch Boxes Thermoforming Machine:

1. Suck and pull the food containers up. Even the containers don't be sucked out successfully, this won't affect next move.
2. There are one conveyor belt on each side, both can achieve automatically stacking, reduce labor intensity.
3. Heater box separate into three parts, hydraulic cutting speed is faster, and use mechanical arms to suck products, all above methods reduce the whole working time.
4. Extend mold length, making the forming mold area larger and improving the production efficiency of this kids plastic lunch boxes thermoforming machine.

Structure & Design

Heating Device

Temperature is controlled precisely (the difference is within ±1℃). The working life of the ceramic heater is long and adopts the fully enclosed oven. The temperature controlling system is better and saves more energy.

Operation Screen

Operator-friendly HMl, and the system has the function of remote connection. lntelligent operation, the whole machine is equipped with formula storage and automatic adjustment without shutdown.

Forming Station

Driven by servo motor to close the mold, with cylinder clamping frame and servo stretching function at the same time.

Punching Station

Has an automatic mold fixing system, which can be fixed after the installation and adjustment. Don't need screws to fix the mold and can short the setting time of the mold. It can improve efficiency.

Cutting Station

The cutter has heat functions. This machine adopts mechanical locking mold, which is safe and reliable; This station uses a pressurized lubrication system to ensure that each hinge point is fully lubricated.

Stacking Station

Stacking station has many options to design that can meet more demands of packing.

FAQ

1. Can this thermoforming machine handle both vacuum and pressure forming methods?

Yes, the thermoforming machines support both vacuum forming and pressure forming techniques, allowing flexible production depending on mold complexity.

2. What thermoplastic materials are compatible with these thermoforming machines?

These machines are compatible with a wide range of thermoplastics including PET, PVC, Polypropylene (PP), and Polystyrene (PS).

3. Are fully automatic configurations available for these thermoforming machines?

Yes, the product range includes manual, semi-automatic, and fully automatic thermoforming machines featuring automatic sheet feeding, cutting, stacking, and inline quality control.

4. What industries commonly use these thermoforming machines?

Industries such as food packaging, automotive manufacturing, medical devices, electronics, and consumer goods extensively utilize these thermoforming machines.

5. How does the machine ensure precision for complex mold shapes?

The machines use precise temperature control and pressure regulation, combined with high-quality molds to achieve detailed and consistent product shapes.
