Plastic Decorative Candle Tray Thermoforming Machine
Model: TTF-520A
Station：Three station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-1.6mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Plastic Decorative Candle Tray Thermoforming Machine
The plastic thermoforming machine can produce high Quality Clear Plastic Tealight Candle Holder for Decoration：
SAMPLE
APPLICATION
Plastic Decorative Candle Tray Thermoforming Machine is used to producing different kinds of trays, lids, bowls, containers, boxes and etc. Suitable material is PP/PS/PET/PVC/HIPS/Corn starch and etc.
The TTF-520A thermoforming machine with smart setting by touch screen and advanced heating system to provide easy operation and best plasticizing effect to ensure quality of finished output products;
Making this machine is completely driven by servo motor. To ensure the stable operation, low noise, high efficiency, high quality.
It is available for PS, PP, PVC, PET,PLA,Corn Starch different kinds of plastic sheet which with the positive and negative air pressure forming and processing high transparency, high stretching, shallow stretching, various geometrical rotation products.
Plastic Decorative Candle Tray Thermoforming Machine of Parameters
| Model | TTF-520A |
| Station | Three station |
| Mould Size (Max.) | 520*400mm |
| Forming Depth (Max.) | 110mm |
| Sheet thickness | 0.2-2mm |
| Forming Speed (Max.) | 40times/min |
| Air pressure | 0.6-0.8mpa |
| Air consumption | 3.0 m³/min |
| Water consumption | 0.7m³/h |
| Sheet width (Max.) | 550mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire |
| Rated power | 120Kw |
| Heating power | 75Kw |
| Procedure | Forming-cutting-stacking |
| Dimension | L9300*W4200*H2800mm |
| Weight | About 9.0T |
Main features
1.The machine is completely driven by servo motor
2. The max forming area is 520x400mm
3. The max forming depth is 100mm
4. Heater is imported from Germany Elstein
Machine detail
EXHIBITION
