Full-automatic Thermoforming Machine
Model: TTF-700A
Max.Forming Area: 700*600 mm
Max.Forming Height: 120mm
Sheet thickness：0.2-2mm
Forming Speed (Max.): 35times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Full-automatic Thermoforming Machine The product is a set of automatic sheet feeding, heating, molding, cutting, stacking one-time completed automatic, efficient plastic sheet molding equipment. It has a Manual. Automatic Plastic Thermoforming Machine uses the latest international plastic sheet forming technology, with an integrated design of machine, electricity, and gas parts. The use of the curved arm of the forming station and the cutting station: is efficient and stable.
An automatic plastic pneumatic and thermal molding machine is an integrated design of machine, electricity, and gas, controlled by microcomputer and PLC, and operated by the man-machine interface.
Full-automatic Thermoforming Machine Technical Parameter:
| Model | TTF-700A |
| Station | Three station |
| Mould Size (Max.) | 700*600 mm |
| Forming Depth (Max.) | 120mm |
| Sheet thickness | 0.2-2mm |
| Forming Speed (Max.) | 35times/min |
| Air pressure | 0.6-0.8mpa |
| Air consumption | 3.6m³/min |
| Water consumption | 0.7m³/h |
| Sheet width (Max.) | 730mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire |
| Rated power | 188Kw |
| Heating power | 118Kw |
| Procedure | Forming-punching-cutting-stacking |
| Dimension | L11500*W4500*H2800mm |
| Weight | About 19.0T |
Application of Full-automatic Thermoforming Machine
The automatic Plastic Thermoforming Machine is suitable for ABS, PS, PE, PET, CPET, APET, PC, PP, PVC, HIPS, PMMA, and other thermoplastic materials. It can produce disposable snack boxes, food boxes, fresh trays, moon cake trays, instant noodle bowl lids, various cup lids, beverage cups, ice cream cups, jelly cups, packaging boxes, bulbs, flower pots, trays, cosmetic linings, daily necessities blister packaging, pharmaceutical blister packaging, alcohol blister packaging, electronic blister packaging, and other products.
Full-automatic Thermoforming Machine Detail
Explore the detailed structure and configuration to see how our machine ensure precision, stability, and efficiency
Feeding Device
Labor & Cost Savings
Improved Efficiency & Productivity
Able to work with double roll
Max.roll diameter: 1000mm
Heating Device
Energy Efficiency save 30%
Elstein ceramic heaters, individually adjustable(line by line)
Can control the temperature by PLC directly
Operation Screen
Live Data Display – Shows temperature, pressure, and cycle status in real time.
mergency Stop & Alarms – Ensures quick response to operational hazards.
Multi-Language Support – Accommodates global operators.
Forming Station
Max mould size:700*550mm
Max depth:120mm
Servo driven plug assist on top forming station
Stable square struction,provide stable forming
Cutting Station
Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force
Stacking Station
Different stacking schemes can be formulated according to the customer's requirements.
Our Services
1. Professional deisgn department.
2. Engineers available to service machinery overseas
3. 13 months warranty.
4. Experienced after-sale department.
