Plastic PS Sheet Line
Single Layer PP/PS Sheet Extruder
APPLICATION AREA
The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistance force in die head extruding channel makes sheet thickness evenly, the internal spiral tank in three rollers ensures an effective cooling and it is easy to change and install net changer with the hydraulic pressure unit, no need to stop machine. The machine extrudes PP/PS granule to PP/PS sheet with single color, which is used for producing plastic products by plastic thermoforming machines, like cups, food container, trays, dishes, bowls, lids, etc.
TECHNICAL PARAMETER | |
Model | TJ-750 |
Suitable Sheet | PP,PS |
Max. Sheet Width | 750mm |
Sheet Thickness Range | 0.25-2.0mm |
Screw Rod Dia. | 110mm |
Screw L/D ratio | 31:1 |
Main Motor Power | 55kw |
Max. Output | 250kg/hr |
Rated Power | 163kw |
Power Supply | AC 380V,50Hz, Three-phase , Four-wire |
Dimension | L12000xW2400xH1800mm |
Weight | About 10.5T |
MACHINE MAIN PARTS | |
Button | Schneider, France |
AC Contactor | |
Circuit Breaker | |
Frequency converter | Delta, Taiwan |
Die Head | Zhengchengda, Huangyan |
Net Changer | |
FAQ | |
Questions | Answer |
what's your product range | Making PP/PS(HIPS) sheet used in plastic forming machine |
What’s the output | 160Kg/h 250kg/h 300kg/h can be customized |
What is finished sheet width | Standard is 670mm and 750mm, but can be customized |
Machine adjustment and installation | We can send technicians go to customers' country for machine adjustment and installation |
Guarantee time and after-sale | One year guarantee time, after one year , we have professional after-sales department providing best service if customer has any problems. |
