PS Extruder
TJ-670 S ingle Layer PP/PS Sheet Extruder APPLICATION AREA The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistance force in die head...
Send Inquiry
Product Introduction
PS Extruder
SAMPLE
APPLICATION of PS Extruder
PS extruder is combined extrusion, calendaring, traction and rolling. The machine is two layer sheet extruder which can make different kinds of disposable cups, food container, trays, lids and etc.
The machine is newly developed with high quality and new technilogy by our engineer team. Three rollers are driven by servo motor.
PS Extruder of Parameters
| Model | TJ-750E |
| Maximum output | 400kg/h@0.7mm |
| Suitable Sheet | PP,PS |
| Sheet Width (Max.) | 750mm |
| Mould width | 950mm |
| Sheet Thickness | 0.3-2.0mm |
| Compressed air source pressure | 0.6-0.8Mpa |
| Screw Rod Dia | 125mm |
| Screw L/D Ratio | 35:1 |
| Max. Output | 400kg/hour |
| Rated Current | 500A |
| Rated Power | 320kW |
| Energy consumption | 220kW |
| Main Motor Power | 160kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L15388*W3615*H2900mm |
| Weight | About 12T |
Use following machine to produce different kinds of plastic products
