Plastic PP Sheet Line

LEVEL THREE ROLL SINGLE MACHINE SHEET MACHINE PRODUCTION LINE: 1.This line includes mainframe extruder, screen changer, mould, embosser, conveyor, traction machine, cutting machine and winder; 2.This gearbox adopts cast steel, alloy steel and by using gear tooth grinding processing, all...

Send Inquiry

Product Introduction

LEVEL THREE ROLL SINGLE MACHINE SHEET MACHINE PRODUCTION LINE:
1.This line includes mainframe extruder, screen changer, mould, embosser, conveyor, traction machine, cutting machine and winder;
2.This gearbox adopts cast steel, alloy steel and by using gear tooth grinding processing, all lubrication points inside the box adopts forced lubrication, lubricating oil with high efficiency water cooling system.
3.This screw material made of 38CrMOA1A high quality steel nitride, and after nitridation, surface spraying alloy.
4.This barrel is made of 38CrMOA1A high quality steel nitride, and after nitridation, surface spraying alloy.
5.Raw materials capable of processing are: PP,PS

Plastic PP Sheet Line of Parameters

Model	TJ-750D
Suitable Sheet	PP,PS
Sheet Width (Max.)	750mm
Mould width	950mm
Sheet Thickness	0.3-2.0mm
Compressed air source pressure	0.6-0.8Mpa
Screw Rod Dia	110mm
Screw L/D Ratio	33:1
Max. Output	240kg/hour
Rated Current	340A
Rated Powe	160kW
Energy consumption	220kW
Main Motor Power	110kw
Power Supply	AC 380V,50Hz, Three-phase, Four-wire
Dimension	L14000W2600H1800mm
Weight	About 8T

SPECIFICS
A. EXTRUDER PART: 1 SET
Output: Max. 250kg/h Screw Dia.: Ф110 L/D: 31:1 Screw & Barrel Material: 38 CrMoAlA after nitrogen treatment with optimum hardness, strong corrosion resistance and long service lifetime. Screw Rotate Speed: 0-70r.p/min. Main Motor Power: 55.0KW. Heating way: Aluminium-casted heater.
B. DIE HEAD PART: 1 SET
Sheet Structure: 1 layer. T-die Design: like cloth-hanger, enable the melting material be flowed evenly from the outlet. Finished Sheet Width: 750mm Sheet Thickness: 0.25mm-2mm. Heating Way: Aluminum-casted heater.
C. FILTER PART: 1 SET
Worm-Gear Case: 1 pc Filter Size: 300mm x 40 mm Net Dia.: Ф3-3.5mm Heating power: 7.2kw Net Changer: By hydraulic system, it includes double filters.

D. 3 ROLLERS PART: 1 SET
Roller No.: 3 pcs Rollers reach to ''mirror surface'' standard Roller linear speed: 0-14m/min Drive motor: 4.0kw Roller part movement: by motor, 1.1kw Roller layout way: by level type, each roller arranged side by side The cooling way: It's gyroidal way (not linear way) to cool each rollers as inside roller has many channel irons.
E.DOUBLE WORKING STATION
Double working station is easy to receive sheet, if one roller is full, we can use another roller , and save time.
F. ROTARY ROLL WINDER
Rewinding receives waste material
