Glass Production Line
Model: TQC-750
Mould Size (Max.): 750mm x 480 mm
Forming Depth (Max.): 180mm
Sheet width (Max.): 770m
Main Motor Power: 188.55KW
Heating Power: 146KW
Dimension: L8500*W2200*H3200mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
TQC-750 Glass Production Line is designed to produce cup shape products. Such as disposable plastic cup, bowls, plates, lids, etc. This plastic cup thermoforming making machine have high productin efficiency with its forming and cutting two-in-one station. Controlled by microcomputer, this cup thermoforming machine can completes the plastic cup production at one time by conveying, heating, forming and cutting, and sheet waste winding.
TQC-750 servo Glass Production Line is suitable for thermoforming of PP, PS, PET, PVC and other plastic sheets. Professional in producing all kinds of cup shape products, such as disposable plastic bowls, plastic plates, plastic water cups, disposable coffee cups, milk tea cups, plastic cup, plastic lids, plastic jelly cups, etc. do you have all in one printing and die cutting paper cup machine
Samples:
Glass Production Line of Parameters
| Model | TQC-750 |
| Mould Size (Max.) | 750*480mm |
| Sheet width | 770mm(Max) |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 770mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 3.0m³/min |
| Water Consumption | 0.7m³/h |
| Rated Power | 173Kw |
| Heating Power | 146Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L8500*W2300*H3300mm |
| Weight | About 8T |
Packing
Quality of Goods:
1)100% brand new, manufactured in the year 2016
2) Origin: China.
Packing and Marking: Packing: Export and sea-worthy standard wooden case
