New Plastic Cup Making Machine
Model: TQC-650B
Mould Size (Max.): 650mm x 300 mm
Forming Depth (Max.): 125mm/180mm
Sheet width (Max.): 660mm
Main Motor Power: 98Kw
Heating power: 78KW
Dimension: L7000 x W2000 x H3100mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
New Plastic Cup Making Machine(Four Pillar type , Hydraulic driven system , and servo motor controlled) with PLC and touch screen operation system more easy to operating; machine mould plate use four pillar type to provide high efficiency and stable forming and running ;heating area designed that seven times size of the heating furnace (here mean the furnace size is seven times the size of mould) it can ensure the good thermoplastic and making products with good performance , and the machine structure adopts 100 *100mm square steel materials with safe structure designed low noise and high efficiency. Suitable for producing plastic cups, fruit containers, bowls, trays, fast food boxes and etc.the machine use multi-rod mechanism system easy to clamping mould closing and help to improve the service life of the machine.It combines the sheet sending heating stretching forming cutting into one process. the machine is suitalbe for pp ps abs, hips pet mateial.
New Plastic Cup Making Machine Technical Parameters
| Model | TQC-750 | TQC-650B |
| Mould Size (Max.) | 750*480mm | 650*300mm |
| Max. Forming Depth | 125-180mm(custom height) | 125mm |
| Max. Forming Speed | 30times/min | |
| Sheet Thickness | 0.3-1.8mm | |
| Suitable Sheet Width | 770mm | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Air Pressure | 0.6-0.8mpa | |
| Air Consumption | 3.0m³/min | 2.0m³/min |
| Water Consumption | 0.7m³/h | 0.5m³/h |
| Rated Power | 173Kw | 98Kw |
| Heating Power | 146Kw | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire | |
| Dimension | L8500*W2300*H3300mm | L7000*W2000*H3100mm |
| Weight | About 8T | About 6T |
New Plastic Cup Making Machine parts:
*Servo Motor (Japan,YASKAWA)Under the condition of stable voltage, Servo motor to feed the sheet precisely to avoid wasting sheet.
*FRL(Filter,Regulator, Lubricator) Steady pressure, Filter water and with compressed air into the pneumatic components(cylinder), and atomize the lubricating oil.
*Large type oil pump motor(Shanghai, dedong 11kw) and oil pump(Joint Venture,SCENERY)
*PLC Siemens, Germany
Circuit Breaker,Air switch (Schneider, France):A switch to control the normal operation of electric currency--protect the machine working.
*Contactor(Schneider, France):Control the load of electrical appliances, protect the electrical circuit.
*Solenoid valve (Japan, SMC) Control cylinder movement.
*Cylinder (China,Kaogeer):Control track backwards,easy to change mould.
*Oven move automaticlly away from sheet when the power cut off：
avoid sheet fall into heating tile to fire.
*waste material receiving holder,Character: the holder combined with
whole machine,can remove up and down,save space.
*cylinder:Kaogeer,China control waste sheet receiving holder move up and down.
*PID termperature systerm:Control temperature for every part.
