CE Standard Automatic Plastic Cup And Lid Thermoforming Machine

Automatic Plastic Cup And Lid Thermoforming Machine adopts Japan Yaskawa servo motor for sheet feeding and stretching, It is an ideal equipment to form PP,PS,HIPS,PVC,PET plastic sheets.Feeding system droved by chain and it adopt cam forming and cutting method. This is an automatic and efficient plastic cup forming machine which include feeding, heating, pulling, forming, cutting and stacking. It combines the preheating, material feeding, heating, drawing, forming, cutting, rewinding into one process.

Parameters of Automatic Plastic Cup And Lid Thermoforming Machine:

Function of Automatic Plastic Cup And Lid Thermoforming Machine:

1. Machine operation is controlled by PLC & Touch screen.
2. Adopt four pillars to fix mold, ensure whole machine precision.
3. Temperature control modules to control each temperature area.

4. Convenient operation, outstanding performance,low noise and high quality.

Samples:

 Structure & Design

Feeding Device

The servo motor-driven automatic loading rack and the double sheet holding station can replace the new sheet roll without stopping the machine, which improves efficiency and saves time.

Material Conveying System

The sheet is smoothly guided into the conveyor chain through transition rollers, ensuring simple operation and more uniform heating across the sheet area.

Heating Device

Two brands of heating tiles are available to meet the needs of customers with different budgets. The heater is added with vacuum insulation cotton, which has fast heating feedback, short heating time and energy saving.

Forming Station

TQC-650B uses in-mold cutting technology, forming and cutting are done at the same station, the product cutting effect is better. The integrated station saves the machine's floor space and reduces customer costs.

Servo Motor

Responsible for driving the stretching head vertically, enabling precise and consistent product forming.

Hydraulic Drive

Exclusively used to drive the lower mold upward to close with the upper mold for product forming.

Operation Screen

Operator-friendly HMl, and the system has the function of remote connection. lntelligent operation, the whole machine is equipped with formula storage and automatic adjustment without shutdown.

Waste Recycling

We have installed a waste reel device under the machine to reel up waste plastic sheets, making it easier for customers to handle waste sheets and reducing labor waste.

Belt-Type Cup Stacker

Optional belt-type cup stacker automatically arranges cups neatly as they drop into the machine, reducing the need for manual cup handling.

FAQ

1. Can this machine produce Biodegradable (PLA) cups?

Yes, absolutely. PLA material is sensitive to temperature. The TQC-750S features German Heaters with Segment Control, allowing for precise temperature management to form PLA sheets perfectly without melting or deforming them.

2. What is the actual production capacity?

The machine runs at a maximum speed of 42 cycles per minute. Your total output depends on the mold layout (cavities). For example, if you use a 32-cavity mold for small water cups, the output would be 32 x 42 = 1,344 cups per minute.

3. How does the control system work?

The machine uses a Micro PLC system combined with a Man-Machine Interface (touchscreen). This allows the entire operation-from material feeding to cutting-to be automated and easily monitored by a single operator.
