Pvc Egg Tray Producing Machine

TTF series PVC egg tray producing machine is forming, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids, etc.

FEATURES AND ADVANTAGES of Pvc Egg Tray Producing Machine

1. High degree of standardization, complete functions, safe, efficient, energy-saving and hygienic.
2. It integrates mechanical, pneumatic and electrical integration, and is controlled by microcomputer and programmable controller (PLC).
3.  Easy-to-operate human-machine interface, and has the function of remote connection.
4. Electric lifting, double-station large-diameter unwinding, allowing a single person to load coils weighing up to 600KG.
5. Servo feeding, stepless adjustment of sheet length, high speed, accuracy and stability.
6. The quick mold change system can conveniently, quickly, accurately and safely change molds, reduce machine downtime, reduce labor waste, and improve production efficiency.
7. The mold opening and closing of the forming, punching and cutting stations are controlled by servo motors, with high precision, low wear, fast speed and low noise. Each station is supported by four columns, combined with a five-point structural connecting rod, which has good stability.
8. The unique vertical stacking concept ensures continuous stacking of products.
9. Automatic counting of finished product output, with production data memory function, can store 90 sets of operating data.
10. Combined with the edge material winding device, the entire production process is clean, without burrs and waste.

Parameters of  Pvc Egg Tray Producing Machine

SAMPLES:

SPECIFICS



1. Working stations adopt four-pillar structure. --more stable and more precise.

2. Touch screen, PLCand servo motor adopt Deltabrand from Taiwan.

3. Sheet feeding driven by servo motor.

4.Heaters adopts "Elstein" from Germany, vacuum insulation cotton--save more energy.

5. Working stations are driven completely byServo motor.

6. Stacking part driven by servo motor.
