Plastic Cup Machine Automatic
Model: TFC-730
Mould Size (Max.): 730×320mm
Forming Depth (Max.): 180mm
Sheet width (Max.): 510-760mm
No-load Speed: 48 Cycles/Min
Main Motor Power: 11.8KW
Heating power: 150.2KW
Dimension: L11000*W2900*H3500mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
Plastic Cup Machine Automatic is designed to produce cup shape products. Such as disposable plastic cup, bowls, plates, lids, etc. This plastic cup thermoforming making machine have high productin efficiency with its forming and cutting two-in-one station. Controlled by microcomputer, this cup thermoforming machine can completes the plastic cup production at one time by conveying, heating, forming and cutting, and sheet waste winding.
Plastic Cup Machine Automatic is suitable for thermoforming of PP, PS, PET, PVC and other plastic sheets. Professional in producing all kinds of cup shape products, such as disposable plastic bowls, plastic plates, plastic water cups, disposable coffee cups, milk tea cups, plastic cup, plastic lids, plastic jelly cups, etc.
These Vedios are machine testing or taken in our old customers factory.You can get large profit from this machine as they do.
Plastic Cup Machine Automatic----Technical Parameter
| Model | TFC-730 |
| Mould Size (Max.) | 730*320mm |
| Sheet width | 510~760mm |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 16-42times/min |
| Sheet Thickness | 0.3-2.0mm |
| Suitable Sheet Width | 510-760mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 4-5m³/min |
| Water Consumption | 15.6m³/h |
| Rated Power | 188.5Kw |
| Heating Power | 151.7Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L10700*W3000*H3215mm |
| Weight | About 15T |
Plastic Cup Machine Automatic ----Application&Features
This thermoforming machine used for producting high demand of disposable fresh/fast food,fruit plastic cups,boxex,plates,container,and pharmaceutical,wine,electrical blister packaging,PP,PS,PET,PVC,OPS plastic sheet etc.Electric furnace temperature control system uses intelligent automatic compensation control,a control,a control of a regulator,easy to adjust the temperature uniformity,easy to use,simple,fast heating,low temperature three times up and down the oven roast slices.Forming,cutting die servo-driven,two-way adjustable for upper and lower mold stroke,in which the upper mold electric adjustable in clamping direction. The upper and bwer molds height position can be adjusted conveniently and fast under the clamping state;lower mold in clamping direction readily accessible buffer,increasing the clamping speed,avoiding shock.
Auto cutting,auto counting,auto transmission by PLC.
Labor saving,only 1-2 workers packing.
Plastic Cup Machine Automatic ---- Samples
Structure & Design
Heating Device
The upper heating size is 3263x900mm with 13 zones, and the lower heating size is 3023x900mm with 12 zones. total 25 zones of PID automatic temperature control regulation.It is equipped with German ceramic heaters with insulation, quick response rate, short processing time, and save energy.
Forming Station
It adopts 17.3kw servo motor.
The upper mould can be adjusted by hand, to fit for products in different height.
The mould platform adopts high-strength ductile iron,the connecting rods of each joint are processed from high-strength cast steel (ZG45).
Robotic Arm
The machine is equipped with a suction-cup robotic arm that picks up the cups from the forming mold and places them into the stacking unit.
Cup Stacking Unit
The stacking unit is configured according to the mold layout, with vertical guide posts installed to keep the cups securely positioned between them and prevent falling. Once the preset stacking quantity is reached, the unit is transferred along the guide rail into the flipping mold.
Flipping Mold
After the cups are pushed into the flipping mold, the mold rotates 90° clockwise and moves along the upper guide rail to the conveyor. The cup pushing mechanism then ejects the cups from the mold onto the conveyor belt.
Cup Pushing Device
Driven by a servo motor, the cup pushing device slides upward to transfer the cups from the stacking unit into the flipping mold.
Conveyor Belt
The cup pushing device ejects the cups from the flipping mold onto the conveyor belt, which then transports them to the packaging machine.
Cup Pushing Device
The device pushes the cups from the conveyor belt into the packaging machine's conveyor, arranging them row by row.
Online Crushing
The production waste is conveyed through the upper track of the machine into the online crusher, where it is crushed into plastic granules for reuse.
