Products
Plastic Cup Disposable Machinery
The TQC-750S is engineered for mass production of:
Beverage Cups: Water cups, Coffee cups, Bubble tea cups (PP/PET).
Dairy Packaging: Yogurt cups, Ice cream cups, Jelly cups.
Eco-Friendly Packaging: PLA biodegradable cups and bowls.
Invest in High Speed: Ready to upgrade your output to 42 cycles/minute?
TQC-750 Plastic cup disposable machinery is designed to produce cup shape products. Such as disposable plastic cup, bowls, plates, lids, etc. This plastic cup thermoforming making machine have high productin efficiency with its forming and cutting two-in-one station. Controlled by microcomputer, this cup thermoforming machine can completes the plastic cup production at one time by conveying, heating, forming and cutting, and sheet waste winding.
TQC-750 Plastic cup disposable machinery is suitable for thermoforming of PP, PS, PET, PVC and other plastic sheets. Professional in producing all kinds of cup shape products, such as disposable plastic bowls, plastic plates, plastic water cups, disposable coffee cups, milk tea cups, plastic cup, plastic lids, plastic jelly cups, etc.
Plastic Cup Disposable Machinery----Characteristics
1. The machine is controlled by PLC and use touch panel.
2. Use servo engine on feeding device and stretching device.
3. Automatic function help manufacturers which produce plastic products to reduce labor and production cost.
4. Fast speed is available for high-level production line.
5. The equipment has mold memory function
Plastic Cup Disposable Machinery----Technical Parameters
| Model | TQC-750S |
| Mould Size (Max.) | 750*480mm |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 770mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 3.0m³/min |
| Water Consumption | 0.7m³/h |
| Rated Power | 207Kw |
| Heating Power | 180Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L7900*W2300*H3400mm |
| Weight | About 8.2T |
Plastic Cup Disposable Machinery----Samples
FAQ
1. Can this machine produce Biodegradable (PLA) cups?
Yes, absolutely. PLA material is sensitive to temperature. The TQC-750S features German Heaters with Segment Control, allowing for precise temperature management to form PLA sheets perfectly without melting or deforming them.
2. What is the actual production capacity?
The machine runs at a maximum speed of 42 cycles per minute. Your total output depends on the mold layout (cavities). For example, if you use a 32-cavity mold for small water cups, the output would be 32 x 42 = 1,344 cups per minute.
3. How does the control system work?
The machine uses a Micro PLC system combined with a Man-Machine Interface (touchscreen). This allows the entire operation-from material feeding to cutting-to be automated and easily monitored by a single operator.
