Disposable Plastic Food Container Machine
TTF series thermoforming machine is forming, punching,cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic food containers, boxes, lids, etc.
Send Inquiry
Product Introduction
TTF-700A Three Stations Disposable Plastic Food Container Machine
The forming type of this Disposable Plastic Food Container Machine is positive pressure and negative pressure combined, which is the distinct advantage of our machine. It needs vacuum pump for complexed samples, add vacuum vent when making moulds for this Disposable Plastic Food Container Machine.
Disposable Plastic Food Container Machine of Technical parameters
| Model | TTF-700AF | TTF-700A |
| Mould Size (Max.) | 700*550 mm | 700*550 mm |
| Forming Depth (Max.) | 120mm | 120mm |
| Sheet thickness | 0.2-1.6mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.6m³/min | 3.4m³/min |
| Water consumption | 0.7m³/h | |
| Sheet width (Max.) | 730mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Rated power | 211Kw | 188Kw |
| Heating power | 118Kw | 118Kw |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L13000*W4500*H2800mm | L11500*W4500*H2800mm |
| Weight | About 25.0T | About 19.0T |
