PET Material Fruit Tray Thermoforming Machine
Model: TTF-520A
Station：Three station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-1.6mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
PET Material Fruit Tray Thermoforming Machine use PLC touch screen controlling the feeding sheet,heating,vacuum forming,cooling,automatic take the sheet out of press mouldingand cutting,use famous pneumatic control system,working stable, and easy foroperation.It is suitable to form HIPS, PS, PVC and PET plastic sheets etc., which can various of seed tray, nursery tray, seedling tray and flower pot.
PET Material Fruit Tray Thermoforming Machine Detail
1. Introduction of food tray making machine:
TTF series plastic thermoforming machine is a combination of mechanical, electrical and pneumatic components, and the whole system was controlled by micro PLC. It is operates with man-interface, which can works all by itself. It combines the material feeding, heating, drawing, forming, cutting into one process.
2. Main features of food tray making machine:
It is used for forming PP, PS, HIPS, PVC and PET plastic sheets, which can be widely used to produce all kinds of plastic boxes, containers and other plastic wares, such as ice-cream cups, milk cups chocolate package boxes, candy boxes and fast-food boxes etc.
PET Material Fruit Tray Thermoforming Machine Parameters
| Model | TTF-520AF | TTF-520A |
| Station | Four station | Three station |
| Mould Size (Max.) | 520*400mm | |
| Forming Depth (Max.) | 110mm | |
| Sheet thickness | 0.2-1.6mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.0m³/min | |
| Water consumption | 0.7m³/h | |
| Sheet width (Max.) | 550mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Rated power | 136Kw | 120Kw |
| Heating power | 75Kw | 75Kw |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L10800*W4650*H2670mm | L8200*W4650*H2670mm |
| Weight | About 11.0T | About 9.0T |
FAQ:
1.Are you a manufacturer?
Yes, we are a professional manufacturer.
2.What about the payment term ?
30%T/T deposit, the rest need be paid by TT before shipment.
3.what about the deliverytime for machine?
For normal speed 30~60 days .
4.Guarantee time and after-sale
One year guarantee time, after one year , we have professional after-sales department providing
best service if customer has any problems
