Disposable Plastic Cups Manufacturing Machine
Model: TFC-730
Mould Size (Max.): 730×320mm
Forming Depth (Max.): 180mm
Sheet width (Max.): 510-760mm
No-load Speed: 48 Cycles/Min
Main Motor Power: 11.8KW
Heating power: 150.2KW
Dimension: L11000*W2900*H3500mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
The disposable plastic cups manufacturing machine is a professional equipment that integrates efficiency, flexibility and intelligent control, and is designed to provide customized solutions for various food and beverage companies. The equipment can efficiently produce disposable plastic cups of different specifications and materials to meet various market needs, such as fast food, takeaway, cold drinks and hot drinks. With its modular design and high degree of automation, the machine has a significant differentiated competitive advantage in the field of plastic cup manufacturing.
Parameters of Disposable Plastic Cups Manufacturing Machine
| Model | TFC-730 |
| Mould Size (Max.) | 730*320mm |
| Sheet width | 510~760mm |
| Max. Forming Depth | 180mm |
| Max. Forming Speed | 16-42times/min |
| Sheet Thickness | 0.2-2.0mm |
| Suitable Sheet Width | 510-760mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 4-5m³/min |
| Water Consumption | 15.6m³/h |
| Rated Power | 188.5Kw |
| Heating Power | 151.7Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L10700*W3000*H3215mm |
| Weight | About 15T |
Disposable Plastic Cups Manufacturing Machine of Application scenarios
Disposable plastic cups manufacturing machines are not limited to the field of beverage packaging, but can also be used for packaging and production of foods such as ice cream, salads, fruit cups, yogurt, etc. It is particularly suitable for large chain catering companies, takeaway service providers, and fast food restaurants in shopping malls that require diversified packaging solutions.
Product highlights of Disposable Plastic Cups Manufacturing Machine
Modular design for flexible production
The modular structure allows users to select functional modules (e.g., quick mold change, automatic stacking) as needed, enabling easy production adjustments and rapid response to market changes.
Intelligent control system
Equipped with an advanced PLC and touch screen, it supports real-time monitoring, remote control, and automated adjustment based on materials and production needs, reducing manual effort and optimizing efficiency.
Precision production with less waste
High-precision molding ensures consistent thickness, weight, and shape. An intelligent detection system automatically removes defective products, reducing material waste and improving yield-ideal for large-scale cup production.
Green material compatibility
Supports traditional materials (PP, PET) as well as eco-friendly options like PLA, meeting market demand for sustainable packaging.
Low noise, high efficiency
Advanced silent technology keeps noise low even during high-intensity operation, improving the factory environment while enabling 24/7 production.
Personalized customization
Supports direct printing of brand logos and patterns on cups, reducing post-processing and costs-perfect for brands seeking rapid, trend-aligned product launches.
Structure & Design
Sheet Conveying
Heating Device
Operation Screen
Mould Part
Flipping Cup Receiving Device
Cup Sweeping and Pushing Device
Cup Conveyor Belt
Waste Recycling
After-sales and support
We provide users with a full range of after-sales services, including online remote support, on-site technical guidance, and regular equipment maintenance recommendations. Free maintenance is provided during the warranty period to ensure stable operation of the equipment, and regular upgrades and optimization recommendations are provided to customers to help improve long-term production benefits.
Conclusion
With modular design, intelligent control and green environmental compatibility, the disposable plastic cups manufacturing machine not only meets the high efficiency requirements of the modern market, but also takes into account environmental trends and personalized needs. It is an ideal choice for the fast food, beverage and food packaging industries to increase production capacity and innovation. This equipment not only improves production flexibility, but also provides strong support for customers' brand building and market competition.
