Plastic Biscuits Storage Container Food Container Thermoforming Machine
Model: TTF-520A
Station：Three station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-2mm
Forming Speed (Max.):40times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Application of Food Container Thermoforming Machine
Plastic Biscuits Storage Container Food Container Thermoforming Machine is applied to producing different kinds of containers, lids, trays, dishes, bowls, boxes which is applying for the package of eggs, cakes, cookies, sushi, sandwich, fruit, meat and etc.
Food Container Thermoforming Machine Parameters
| Model | TTF-520A |
| Station | Three station |
| Mould Size (Max.) | 520*400mm |
| Forming Depth (Max.) | 110mm |
| Sheet thickness | 0.2-2mm |
| Forming Speed (Max.) | 40times/min |
| Air pressure | 0.6-0.8mpa |
| Air consumption | 3.0 m³/min |
| Water consumption | 0.7m³/h |
| Sheet width (Max.) | 550mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire |
| Rated power | 120Kw |
| Heating power | 75Kw |
| Procedure | Forming-cutting-stacking |
| Dimension | L9300*W4200*H2800mm |
| Weight | About 9.0T |
Machine detail
Architectural design & planning cepteur sint occaecat cupidatat proident
Heating Device
Brand is Elstein Germany, with fast heating reaction and high thermal effect, energy saving and more safety.
Operation Screen
It can adjust parameter data in touch screen directly when you change mould and adjust machine.
Forming Station
Forming area: 520*400mm, bigger forming area with high capacity, faster change mould. it has a double safety bolt to ensure safety.
Cutting Station
Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force
Stacking Station
Stacking station：Stacking station has many options to design that can meet more demands of packing.
Waste recycling
Asynchronous winder motor with electronic torque control.
Pneumatic discharging system of scrap.
Main Features of Food Container Thermoforming Machine
1. The machine is totally driven by servo motor.
2. The machine working process is: sheet loading-sheet feeding-heating-forming-cutting-stacking-waste material rewinder-finished products. It is full automatic which only needs one labor
3. Touch screen and PLC adopts DELTA from Taiwan
4. For sheet loading, it is a separate part which can hold at least 500kg at one time.
