Plastic Cup Making Machine

Plastic Cup Making Machine-----Application & Features

TQC-750 plastic thermoforming machine(plastic cup making machine) adopt servo motor for sheet feeding and streching, PLC for programe, touch screen for operation, stable, low noise and high efficiency.  Suitable for producing plastic cups, fruit containers, bowls, trays, fast food boxes and etc.

Minimize plastic waste by using servo motor drive system accurate index accuracy

Positive and negative forming (pressure forming plus vacuum forming)

Automatic stacking, counting and conveying system

Access all digital features by pressing the touch screen

Touch screen and programmable PLC control

Temperature control ensures precise temperature accuracy

Low maintenance workload and long maintenance intervals

Most components come from multinational suppliers, ensuring reliability and global compatibility

Parameters of Plastic Cup Making Machine

Plastic Cup Making Machine-----Finished Products:

Functional Characteristics Of Our Servo Plastic Cup Making Machine?

1. Fully servo-driven, silent, vibration-free, excellent thermoforming, and high speed.
2. Compact design, occupying minimal floor space.
3. Integrates sheet feeding, heating, stretching, forming, and trimming in one process.
4. Automatic unloading device allows adjustable production parameters without material waste.
5. One-to-one intelligent temperature control system in the electric furnace for even heating, energy efficiency, rapid temperature rise, and three low-temperature baking cycles.
6. Servo-driven forming and cutting molds with bi-directionally adjustable stroke; the upper mold's closing direction is electrically adjustable for easy height adjustments and faster, vibration-free operation.
7. PLC for automatic cutting, counting, and transportation.
8. Only 1-2 operators needed for packing.
