Products
Automatic Dish Forming Machine
Model: TQC-650B
Mould Size (Max.): 650mm x 300 mm
Forming Depth (Max.): 125mm/180mm
Sheet width (Max.): 660mm
Main Motor Power: 98Kw
Heating power: 78KW
Dimension: L7000 x W2000 x H3100mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
Automatic Dish Forming Machine Technical parameters
| Model | TQC-650B |
| Mould Size (Max.) | 650*300mm |
| Sheet width | 660mm(Max) |
| Max. Forming Depth | 125-180mm(custom height) |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 2.0m³/min |
| Water Consumption | 0.5m³/h |
| Rated Power | 98Kw |
| Heating Power | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L7000*W2000*H3100mm |
| Weight | About 6T |
Automatic Dish Forming Machine Application
Automatic dish forming machine is suitable to produce different kinds of dishes, disposable cups, bowls, ice cream cups, corn starch food containers and etc. It is full automatic and suitable to produce different PP/PS/PET/PVC/HIPS/Corn Starch material sheet.
Machine Main Features
1.The machine can be lubricated automatically at fixed time
2. It is automatic sheet load, save more labor cost
3. The waste material can be rewinded automatically and use crusher to recycle
4. PLC and touch screen use Simens, quality guaranteed.
Packing
FAQ
1.Why choose us?
We have 25 years experience in this industry and we have good sales and after-service team to help customer.We have CE and ISO 9001 certification.We have professional engineer to go to customer's factory to install the machine and work training
2. Where is your factory located?
Our factory is located at Rui'an city, Zhejiang Province, which is convinient from Shanghai by High speed train or By Air.
