Automatic Plastic Container Making Machine

Automatic Plastic Container Making Machine


Model: TTF-520A
Station:Three station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness:0.2-2mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Send Inquiry
Product Introduction

Automatic Plastic Container Making Machine Features

1. The machine is completely driven by servo motor, more stable.

2. Suitable material is PP/PS/PET/HIPS/PVC/Corn Starch and etc.

3. Max forming area is 520x400mm

4. It is easy and quickly to change the mould by making different goods.

5. Upper mould and lower mould are all driven by servo motor.

6. The max speed can readh 30 cycles per min.

Automatic Plastic Container Making Machine Technical Parameters

Model TTF-520A
Station Three station
Mould Size (Max.) 520*400mm
Forming Depth (Max.) 110mm
Sheet thickness 0.2-2mm
Forming Speed (Max.) 40times/min
Air pressure 0.6-0.8mpa
Air consumption 3.0 m³/min
Water consumption 0.7m³/h
Sheet width (Max.) 550mm
Suitable Sheet PP, PS, HIPS, PET, PVC, PLA etc.
Power supply AC 380V, 50Hz, Three-phase, Four-wire
Rated power 120Kw
Heating power 75Kw
Procedure Forming-cutting-stacking
Dimension L9300*W4200*H2800mm
Weight About 9.0T

APPLICATION of Automatic Plastic Container Making Machine

Automatic Plastic Container Making Machine is used to producing different kinds of egg trays, cracker box, fruit tray, medical tray, electric packaging box and etc. Suitable material is PP/PS/PET/PVC/HIPS/Corn starch and etc.

product-1000-750
product-1000-750
product-1000-750
product-1000-750
product-1000-750
product-1000-750

Automatic Plastic Container Making Machine Main features:

1.Multi-station operation:

  • Heating station: The plastic sheet is heated to the softening temperature at this station in preparation for molding.
  • Forming station: The heated plastic sheet is transferred here and molded into the desired product shape under pressure using molds.
  • Cutting station: The formed product moves to this station for precise cutting and trimming.

2.High production efficiency: High degree of automation: Modern three-station thermoforming machines typically feature advanced automation control systems, including PLC control and human-machine interface (HMI). These systems enable precise control over temperature, pressure, and time to ensure consistent product quality.

3.Strong flexibility: By adjusting process parameters and changing molds, it can produce products of different shapes, sizes, and thicknesses, making it widely applicable across industries.

4.Energy consumption optimization: They use high-efficiency heating elements, optimize thermal cycles, and recover waste heat to significantly reduce energy costs.

5.Easy maintenance: Its modular design facilitates easy disassembly and replacement of components, minimizing equipment downtime and maximizing utilization.

6.High safety: The equipment incorporates multiple safety measures such as overheating protection, overload protection, and emergency stop buttons to ensure operator safety.



Structure & Design

Explore the detailed structure and configuration to see how our machine ensure precision, stability, and efficiency

Heating device

Heating Device

Energy Efficiency save 30%
Elstein ceramic heaters, individually adjustable(line by line)
Can control the temperature by PLC directly

Operation screen



Operation Screen

Live Data Display – Shows temperature, pressure, and cycle status in real time.

mergency Stop & Alarms – Ensures quick response to operational hazards.

Multi-Language Support – Accommodates global operators.

Forming station

Forming Station

Max mould size:520*400mm
Max depth:110mm
Servo driven plug assist on top forming station
Stable square struction,provide stable forming

Cutting station

Cutting Station

Servo motor driven Movable cutters, to adjust the cutting by itself High-quality cutters, save spare parts costs Top nut locking structure, providing stronger force

Stacking station

Stacking Station

Different stacking schemes can be formulated according to the customer's requirements.

8

Waste Recycling

Edge trim is fed to the waste rewinding system for recycling. Its special clutch automatically cuts power when the roll becomes too large, preventing overload and extending motor lifespan.
