Disposable Plastic Lunch Bento Box Making Machine
High Efficiency: Reduces cycle time by 30% with servo-motor drive.
Precision: ±0.01mm repeatability for complex forming.
Certified: CE & ISO 9001 Compliant standards.
Customizable: Worktable size and stroke tailored to needs.
Disposable Plastic Lunch Bento Box Making Machine is mainly used for the production, the production of disposable tableware, cold drink cup, yogurt cup, jelly cup, ice cream cups, snack box, etc. At the same time can also processing and pharmaceutical,light industry, textile, tourism, toys and other plastic packaging products.
The characteristics of the plastic cup machine:
1.High efficiency, energy saving, security, environmental protection, high product quality.
2.To adapt to the wide raw materials. Such as PS, PP, PVC, PET, and other plastic sheet can be processed.
3. The machine is driven by hydraulic system
Samples
Disposable Plastic Lunch Bento Box Making Machine Parameter
| Model | TQC-750 | TQC-650B |
| Mould Size (Max.) | 750*480mm | 650*300mm |
| Max. Forming Depth | 125-180mm(custom height) | 125mm |
| Max. Forming Speed | 30times/min | |
| Sheet Thickness | 0.3-1.8mm | |
| Suitable Sheet Width | 770mm | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Air Pressure | 0.6-0.8mpa | |
| Air Consumption | 3.0m³/min | 2.0m³/min |
| Water Consumption | 0.7m³/h | 0.5m³/h |
| Rated Power | 173Kw | 98Kw |
| Heating Power | 146Kw | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire | |
| Dimension | L8500*W2300*H3300mm | L7000*W2000*H3100mm |
| Weight | About 8T | About 6T |
Cup Production Line
Why you choose your company?
1) We are China Leading machine Manufacturer.
2) Our company have mademachine about 20 years with strong experience and advanced technology.
3) Best Quality &Service with Reasonable price.
4)100% inspection Before Shipment.Quality is priority. we always attach great importance to quality
controlling from the very beginning to the very end.Our factory has gained government authentication.
