Sugarcane Bagasse Disposable Bowl Making Machine
Model: TQC-650B
Mould Size (Max.): 650mm x 300 mm
Forming Depth (Max.): 125mm/180mm
Sheet width (Max.): 660mm
Main Motor Power: 98Kw
Heating power: 78KW
Dimension: L7000 x W2000 x H3100mm
Suitable Sheet Material:PP / PET / PVC / PS / HIPS / GPPS / Biodegradable Materials
Sugarcane bagasse disposable bowl making machine is mainly suitable for raw sheet PS, expansion PP, PET, biodegraded PP, etc to make all kinds of thin & open container through vacuum forming process, for example, many kinds of disposable lunch box, fast food plate, instant noodle bowl, western food box, inner lining of food packing, ice cream cup, candy box, cake component, hardware, etc as well as breeding plate for farm crops and vegetables.
Sugarcane Bagasse Disposable Bowl Making Machine of Features:
1. The stretching plug inside of the upper mould is controlled by air cylinder.
2. The sheet feeding is controlled by normal motor with encode.
3. Adopts two pillars to fix the mould.
4. The upper mould is fixed and the under movement is driven by hydraulic pressure
5. Each area temperature is controlled by one temperature controller
6. All-digital control system uses dedicated controller, multiple CPU processing division, a multi-functional automatic fault detection, alarm system.
7. System is of high stability and responsiveness. System uses man made interface for easy operation and
with a number of peripheral interfaces.
Sugarcane Bagasse Disposable Bowl Making Machine of Parameter:
| Model | TQC-650B |
| Max Forming Area | 650*320mm |
| Max Forming Depth | 125mm |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 660mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 2.0m³/min |
| Water Consumption | 0.5m³/h |
| Rated Power | 98Kw |
| Heating Power | 78Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L7000*W2000*H3100mm |
| Weight | About 6T |
FAQ
Can this machine produce Biodegradable (PLA) cups?
Yes, absolutely. PLA material is sensitive to temperature. The TQC-750S features German Heaters with Segment Control, allowing for precise temperature management to form PLA sheets perfectly without melting or deforming them.
What is the actual production capacity?
The machine runs at a maximum speed of 42 cycles per minute. Your total output depends on the mold layout (cavities). For example, if you use a 32-cavity mold for small water cups, the output would be 32 x 42 = 1,344 cups per minute.
How does the control system work?
The machine uses a Micro PLC system combined with a Man-Machine Interface (touchscreen). This allows the entire operation-from material feeding to cutting-to be automated and easily monitored by a single operator.
