Disposable Frozen Food Packaging Tray Thermoforming Machine
Model: TTF-520A
Station：Three station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-1.6mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Disposable Frozen Food Packaging Tray Thermoforming Machine is mainly used for thermoforming of plastic sheets such as PVC, HIPS, PET, PS, PP, corn starch etc. processing high transparency, high stretch, shallow stretch, round, square, upper and lower two-way stretch, flanged and other products, including trays, lids, fruit and vegetable boxes, flower pots, shells, seedling trays and plates, etc.
Feature OF Disposable Frozen Food Packaging Tray Thermoforming Machine
1. The new type of electric furnace, the upper and lower furnace heating frames are all designed with high temperature resistant aluminum alloy material, with low weight, low cost, fast heat dissipation and simple appearance. The heater adopts the heater of ELSTEIN of Germany.
2. Each servo motor is equipped with a thermal protection device to prevent the servo motor from being overloaded and over-current due to long-term operation and damaging the device. Each motor is equipped with an overcurrent protection device.
3. The machine is completely by servo motor
SAMPLES
Paramenters of Disposable Frozen Food Packaging Tray Thermoforming Machine
| Model | TTF-520A |
| Station | Three station |
| Mould Size (Max.) | 520*400mm |
| Forming Depth (Max.) | 110mm |
| Sheet thickness | 0.2-2mm |
| Forming Speed (Max.) | 40times/min |
| Air pressure | 0.6-0.8mpa |
| Air consumption | 3.0 m³/min |
| Water consumption | 0.7m³/h |
| Sheet width (Max.) | 550mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire |
| Rated power | 120Kw |
| Heating power | 75Kw |
| Procedure | Forming-cutting-stacking |
| Dimension | L9300*W4200*H2800mm |
| Weight | About 9.0T |
Machine Detail
