Full Automatic Disposable Plastic Egg Tray Thermoforming Machine
Model: TTF-520AF
Station：Four station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-1.6mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Description:
Fully automatic positive and negative pressure three-station thermoforming machine for PS, PE, PET, PP, PVC, HIPS and other thermoplastic materials with a thickness of 0.2-2.0mm, high transparency and high processing Stretching, shallow stretching, round, square, irregular, up and down biaxial stretching, flanging and other products, can produce disposable snack boxes, food boxes, fresh trays, moon cake trays, instant noodle bowls, all kinds of cups Cover, beverage cup, ice cream cup, jelly cup, packaging box, blister, flower pot, tray, cosmetic lining, daily necessities blister packaging, pharmaceutical blister packaging,etc
Main Functions:
1.positive and negative pressure forming device.
2.vacuum forming device.
3.touch screen computer temperature module point to point control function.
4.air control device.
5.cooling device.
6.die, mold temperature control function.
7.automatic punching and cutting function.
8.automatic stack counting function.
9.edge automatic rewinding function.
10.safety protection device.
Technical Parameters:
| Model | TTF-520AF | TTF-520A |
| Station | Four station | Three station |
| Mould Size (Max.) | 520*400mm | |
| Forming Depth (Max.) | 110mm | |
| Sheet thickness | 0.2-1.6mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.0m³/min | |
| Water consumption | 0.7m³/h | |
| Sheet width (Max.) | 550mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Rated power | 136Kw | 120Kw |
| Heating power | 75Kw | 75Kw |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L10800*W4650*H2670mm | L8200*W4650*H2670mm |
| Weight | About 11.0T | About 9.0T |
Finished Samples:
