Plastic Paper Cup Screen Printing Machine
Maximum forming layout: 750 * 480MM, can accommodate thermoformed products with various diameters and more cavities
Production speed: 15-32 molds/mins, significantly improving production efficiency
Material compatibility: PP, PS, HIPS, PET, PVC, PLA etc.
The TQC-750S is a fully automatic Plastic Cup Thermoforming Machine with 6-Axis Servo Control. Max speed 42 cycles/min. Supports PP, PET,PVC,PS, HIPS and Biodegradable PLA sheets.
It is suitable for producing pp cups, disposable food container, plastic bowls, cups, trays, plates, containers, etc.Stable operation and reliable performance, low noise, high quality.
Thermoforming Plastic Cup Making Machine----Features:
1.The stretching of plug inside of up mould is controlled by servo motor.
2.The operation controller --adopts hanging type screen,ues Siemens,Germany
3. It uses import famous brands of electric and pneumatic fittings, so the operation is stable, quality is reliable and life is long.
4.Mechanism movement adds automatically oil to lubricate at certain times.
5.Temperature control modules to control each temperature area.
Plastic Paper Cup Screen Printing Machine Parameters
| Model | TQC-750 |
| Mould Size (Max.) | 750*480mm |
| Max. Forming Depth | 125-180mm(custom height) |
| Max. Forming Speed | 30times/min |
| Sheet Thickness | 0.3-1.8mm |
| Suitable Sheet Width | 770mm |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. |
| Air Pressure | 0.6-0.8mpa |
| Air Consumption | 3.0m³/min |
| Water Consumption | 0.7m³/h |
| Rated Power | 173Kw |
| Heating Power | 146Kw |
| Power Supply | AC 380V,50Hz, Three-phase, Four-wire |
| Dimension | L8500*W2300*H3300mm |
| Weight | About 8T |
Thermoforming Plastic Cup Making Machine----Finished Samples
