Plastic Food Container Machinery
TTF series thermoforming machine is forming, punching,cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic food containers, boxes, lids, etc.
Send Inquiry
Product Introduction
Plastic Food Container Machinery
Plastic Food Container Machinery---Application:
Plastic Food Container Machinery---Main Technical Parameter:
| Model | TTF-700AF | TTF-700A |
| Mould Size (Max.) | 700*550 mm | 700*550 mm |
| Forming Depth (Max.) | 120mm | 120mm |
| Sheet thickness | 0.2-1.6mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.6m³/min | 3.4m³/min |
| Water consumption | 0.7m³/h | |
| Sheet width (Max.) | 730mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Rated power | 211Kw | 188Kw |
| Heating power | 118Kw | 118Kw |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L13000*W4500*H2800mm | L11500*W4500*H2800mm |
| Weight | About 25.0T | About 19.0T |
Plastic Food Container Machinery---Specification
1.Working stations adopt four-pillar structure.--morestable and more precise.
2.Touch screen, PLCand servo motor adoptDelta brand from Taiwan.
3. Sheet feeding driven by servo motor.
4.Heaters adopts"Elstein" from Germany, vacuuminsulationcotton--savemoreenergy.
5. Working stations are driven completely by Servomotor.
6. Guiding parts adopt crank-link mechanism to improve work efficiency.
