Transparent Clamshell Fruit Box Making Machine
Model: TTF-520AF
Station：Four station
Max.Forming Area: 520*400mm
Max.Forming Height: 110mm
Sheet thickness：0.2-1.6mm
Forming Speed (Max.): 30times/min
Power supply: AC 380V, 50Hz, Three-phase, Four-wire
Application: trays, containers, boxes, lids, etc.
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump
Suitable Material: PP, PS, HIPS, PET, PVC, PLA etc.
Application:
TTF series thermoforming machine is forming, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids. This transparent clamshellf fruit box making machine is developed by combining the domestic and foreign equipment and advantages, it can produce PS,PVC,PE,PP,PET,HIPS etc all kinds of packaging products, materials used in food, medical supplies, electrical components, tourism products, toys, textile, etc.
Samples:
Transparent Clamshell Fruit Box Making Machine Parameter:
| Model | TTF-520AF | TTF-520A |
| Station | Four station | Three station |
| Mould Size (Max.) | 520*400mm | |
| Forming Depth (Max.) | 110mm | |
| Sheet thickness | 0.2-1.6mm | |
| Forming Speed (Max.) | 30times/min | |
| Air pressure | 0.6-0.8mpa | |
| Air consumption | 3.0m³/min | |
| Water consumption | 0.7m³/h | |
| Sheet width (Max.) | 550mm | |
| Suitable Sheet | PP, PS, HIPS, PET, PVC, PLA etc. | |
| Power supply | AC 380V, 50Hz, Three-phase, Four-wire | |
| Rated power | 136Kw | 120Kw |
| Heating power | 75Kw | 75Kw |
| Procedure | Forming-punching-cutting-stacking | |
| Dimension | L10800*W4650*H2670mm | L8200*W4650*H2670mm |
| Weight | About 11.0T | About 9.0T |
What's your advantages ?
--machines designed to quickly adjustable
--machines have good plastic adaptability
--first-rate attractive and reasonable price
--rich experience and professional
--customers all over the world
--certificate: CE certificate for transparent clamshellf fruit box making machine
--fast reply: our team will reply you soon.
--after sale service:We have a after sale department, service for your problems and dealing
with spare parts.
