Plastic Tray Making Machine

Application: TTF series thermoforming machine is forming, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids, etc. Main Technical Parameter: Specification: 1.Working...

Product Details

Plastic Tray Making Machine

Main Function Features



1.Adopt mechanical cam system to operate, convenient to operate and maintain.

2.Completely automatic and fast production speed.

3.By installing different molds to produce different products.

4.Adopt imported famous brands of electric and pneumatic fittings, reliable quality and long life.

Main Technical Parameter:

Model

 TTF-400A

Forming Area

 400mm x 300 mm

Forming Depth (Max.)

 60mm

Sheet thickness

 0.3-1.8mm

Forming Speed (Max.)

 35 times/min

Air pressure

 0.6-0.8mpa

Air consumption

 2 m³/min

Water consumption

 0.7 m³/h

Sheet width (Max.)

 430mm

Suitable Sheet

 PP, PS, HIPS, PET, PVC,etc.

Power supply

 AC 380V, 50Hz, Three-phase, Four-wire

Rated power

 58kw

Procedure

 Forming-cutting-stacking

Dimension

 L5200×W2000×H2400mm

Weight

 5.2T



SAMPLE:

Plastic Tray Making Machine

Mould


Plastic Tray Making MachinePlastic Tray Making Machine



Company Profile


Rui'an Litai Machinery CO.,LTD is founded in 2001. For more than 17 years,
we focus on researching, developing, manufacturing and marketing on thermoforming machine, plastic cup production line, BOPS plastic thermoforming machine, mutil-layer PP/PS/PET sheet extruder, mould, etc.


Packing and Shipping

Plastic Tray Making Machine

Plastic Tray Making Machine


FAQ



1. Q: Are you a factory or trading company?

      A: We are a factory.



2. Q: What certificate do you have?

       A: We have ISO and CE certificate.



3. Q: How does your factory do regarding quality control?

       A: We have a special QC department in charge of products’ quality.



 4. Q: What’s the main market of your company?

      A: We have customers all over the world.



5. Q: Can we visit your machine operation in your factory?

      A: We have own plastic making company, you can see the machine operation.
