Cake Tray Forming Machine



APPLICATION Area

TTF series thermoforming machine is forming, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids, etc.


Cake Tray Forming Machine operation process


It is Sheet feeding-sheet heating-forming station-cutting station-Stacking station-waste material rewinding





Quality Automatic Plastic Egg Tray Forming Machinery / Egg Box Production Line





SAMPLES





Technical Parameter



Model

TTF-520A

Forming Area

520mm x 400 mm

Forming Depth (Max.)

100mm

Sheet thickness

0.3-1.8mm

Forming Speed (Max.)

30 times/min

Air pressure

0.6-0.8mpa

Air consumption

3 m³/min

Water consumption

0.7 m³/h

Sheet width (Max.)

570mm

Suitable Sheet

PP, PS, HIPS, PET, PVC,etc.

Power supply

AC 380V, 50Hz, Three-phase, Four-wire

Rated power

100kw

Procedure

Forming-cutting-stacking

Dimension

L9700×W4600×H2700mm

Weight

About 7.0T


Cake Tray Forming Machine Details



Company Profile


Rui'an Litai Machinery CO.,LTD is founded in 2001. For more than 16 years, our enterprise mission is to realizeproducing automatic plastic packaging machines.We focus on researching,developing, manufacturing and marketingon thermoforming machine, plastic cup production line, BOPS plastic thermoforming machine, mutil-layer PP/PS/PETsheet extruder, mould, etc.We are first manufacturer in domestic to produce plastic cup in one line with thermoforming,stacking, transmitting, counting, and packing automatically. We get a lot of invention patents and utility model patentsfor our products, and our machines have passed CE and ISO 9001:2000 certification. Meanwhile, there are more than72 countries and regions cooperating with us, such as USA, south Korea, Turkey, Canada, Russia, Kuwait, Iran, Brazil,Chile, Bolivia, Saudi Arabia, Yemen, Peru, etc. We insist in "customer goes first, sincere service" as enterprise servicepurpose, and welcome the cooperation and guidance from old and new customers.



FAQ

  1. What is The core strengths of the machine?

Patent product,new generation driven way,special energy-saving.


2. How about Machine adjustment and installation?

We can send technicians go to customers' country for machine adjustment and installation


3. What is guarantee time and after-sale?

One year guarantee time, after one year , we have professional after-sales department providing best service if any problems.
