Polystyrene Sheet Extrusion Line

APPLICATION AREA The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistance force in die head extruding channel makes sheet thickness...

Chat Now

Product Details

Application:

This polystyrene sheet extrusion line is suitable for producing two colors PP/PS sheet. It extrudes granule to sheet which is used for producing different kind of plastic cups, food containers, trays, dishes, bowls, trays, lids, etc.

QQ截图20180226151226.pngpolystyrene sheet extrusion

Main Features:

  • Double -layer sprial co-extrusion die head.

  • Complete inner cooling systerm.

  • Unique separated dies and moulds for each size.

  • Horizontal structure corrugator.

  • Vacuum forming.

  • Double-layer belling inline.

  • The most innovated technology for complete line insures high production speed and perfect out layer,inner layer surface

  • Extruder heating circle is made by aluminum. This is good for heat, not easy to fire.

Samples:

polystyrene sheet extrusion

Technical Parameter:

ModelTJS-670
Suitable SheetPP,PS
Max. Sheet Width670mm
Sheet Thickness Range0.3-2.0mm
Screw rod Dia(main machine)95mm
Screw rod Dia(auxiliary machine)65mm
Screw L/D Ratio(main machine)35:1
Screw L/D Ratio(auxiliary machine)36:1
Main Motor Power75kw
Auxiliary Motor Power22kw
Max. Output250kg/hr
Rated Power238kw
Power Supply
AC 380V,50Hz,Three-phase,Four-wire
DimensionL14000*W2800*H2500mm
WeightAbout 8T
