Food Packaging Box Making Machine

Application: TTF series thermoforming machine is forming, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids, etc. Product Machine detail Main Technical Parameter:...

Product Details


Application:

TTF series thermoforming machine is forming, cutting and stacking in one line. It is completely

driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic

trays, containers, boxes, lids, etc.


 Product


Machine detail


Main Technical Parameter:

Model

 TTF-400A

Forming Area

 400mm x 300 mm

Forming Depth (Max.)

 60mm

Sheet thickness

 0.3-1.8mm

Forming Speed (Max.)

 35 times/min

Air pressure

 0.6-0.8mpa

Air consumption

 2 m³/min

Water consumption

 0.7 m³/h

Sheet width (Max.)

 430mm

Suitable Sheet

 PP, PS, HIPS, PET, PVC,etc.

Power supply

 AC 380V, 50Hz, Three-phase, Four-wire

Rated power

 58kw

Procedure

 Forming-cutting-stacking

Dimension

 L5200×W2000×H2400mm

Weight

 5.2T

Specification:

1.Working stations adopt four-pillar structure. --more stable and more precise.

2.Touch screen, PLC and servo motor adopt Delta brand from Taiwan.

3. Sheet feeding driven by servo motor.

4.Heaters adopts “Elstein” from Germany, vacuum insulation cotton--save more energy.

Samples:


Our Company

Rui'an Litai Machinery CO.,LTD is founded in 2001. For more than 16 years, we focus on researching,

developing, manufacturing and marketing on thermoforming machine, plastic cup production line, BOPS

 plastic thermoforming machine, mutil-layer PP/PS/PET sheet extruder, mould, etc. There are more

than 72 countries and regions cooperating with us, such as USA, south Korea, Turkey, Canada, Russia,

Kuwait, Iran, Brazil, Chile, Bolivia, Saudi Arabia, Peru, etc.
