Automatic Egg Tray Producing Machine

TTF-520A Full -A utomatic four - station Plastic Thermoforming Machine APPLICATION TTF series thermoforming machine is forming, punching , cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic...

Product Details

Automatic Egg Tray Producing Machine


top 10 litai brand best sales plastic container multi station forming machine


 APPLICATION

TTF series thermoforming machine is forming, punching, cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic trays, containers, boxes, lids, etc.

SAMPLES











Product Description

Multi function plastic automatic thermoforming machine, using the latest international plastic sheet forming process technology It uses microcomputer and programmable control PLC control system, the entire system HMI (man-machine interface ). Laser blade punching, heating, forming, cutting, stacking four stations, advanced technology simultaneous running that is plastic sheet sending, heating, forming, punching, cutting, Stacking together to complete the plastic sheeting thermoforming machine.

Technical Parameter:

Model

TTF-520AF

Forming Area

520mm x 400 mm

Forming Depth (Max.)

100mm

Sheet thickness

0.3-1.8mm

Forming Speed (Max.)

30times/min

Air pressure

 0.6-0.8mpa

Air consumption

 3 m³/min

Water consumption

 0.7 m³/h

Sheet width (Max.)

 570mm

Suitable Sheet

 PP, PS, HIPS, PET, PVC,etc.

Power supply

 AC 380V, 50Hz, Three-phase, Four-wire

Rated power

 110kw

Procedure

 Forming-punching-cutting-stacking

Dimension

 L11000*W4600*H2700mm

Weight

 About 8.0T

 Company Profile

Rui'an Litai Machinery is founded in 2001.After more than 18 years’ accumulation,we have our own professional technicians and engineers,besides,we have the ability of developing new products by ourselves.You are always welcome to our factory to have a visit for establishing a long-term and friendly business relationship with us.

Packaging and shipping


WHY CHOOSE US

1. Litai Machine is one of the most important aspects of our industry and a promary focus as we strive to develop the most advanced machines

2. Excellent in Service. When it comes to International trade, supplying great products is only half of the battle.

3. Warranty. We offer 13 months warranty on all of our machines to assist in the installation and proper maintenance.
